Rt032 – Raymarine Pathfinder Radar Scanner User Manual
Page 10
Sheet 2 of 2
Certificate No.
RT032
Declaration of Conformity – Schedule of Ancillary
Equipment and Radar Systems
The following Raymarine Display Units are combined with the Raymarine 4D – 4kW, 24" Radome Scanner
Unit (transceiver) listed on Sheet 1 to form the operational radar systems given below. Details of these units are
included in the Technical Construction File:
DISPLAY (one of)
Description Designation
Part
No.
Display Unit, 7" Mono LCD
SL70M PLUS
E52043
Display Unit, 7" Mono LCD/Chart
SL70MRC PLUS
E52044
Display Unit, 7" Mono LCD/hsb²
RL70 PLUS
E52031
Display Unit, 7" Mono LCD/hsb²/Chart
RL70RC PLUS
E52032
Display Unit, 7" CRT/hsb²
R70 PLUS
E52039
Display Unit, 7" CRT/hsb²/Chart
R70RC PLUS
E52040
Display Unit, 10" CRT/hsb²
R80 PLUS
E52035
Display Unit, 10" CRT/hsb²/Chart
R80RC PLUS
E52036
Display Unit, 7" Colour LCD
SL70C PLUS
E52045/E52045HB
Display Unit, 7" Colour LCD /Chart
SL70CRC PLUS
E52046/E52046HB
Display Unit, 7" Colour LCD/hsb²
RL70C PLUS
E52033/E52033HB
Display Unit, 7" Colour LCD hsb²/Chart
RL70CRC PLUS
E52034/E52034HB
Display Unit, 10" Colour LCD/hsb²
RL80C PLUS
E52037
Display Unit, 10" Colour LCD/hsb²/Chart
RL80CRC PLUS
E52038
Note: Colour LCD Units with "HB" suffix Part No's, have higher brightness displays.
PATHFINDER RADAR SYSTEMS
Designation
Radar System
Scanner Unit
Display Unit
SL74M PLUS
4D
SL70M PLUS
SL74MRC PLUS
4D
SL70MRC PLUS
RL74 PLUS
4D
RL70 PLUS
RL74RC PLUS
4D
RL70RC PLUS
R74 PLUS
4D
R70 PLUS
R74RC PLUS
4D
R70RC PLUS
R84 PLUS
4D
R80 PLUS
R84RC PLUS
4D
R80RC PLUS
SL74C PLUS
4D
SL70C PLUS
SL74CRC PLUS
4D
SL70CRC PLUS
RL74C PLUS
4D
RL70C PLUS
RL74CRC PLUS
4D
RL70CRC PLUS
RL84C PLUS
4D
RL80C PLUS
RL84CRC PLUS
4D
RL80CRC PLUS
