5 RF-NANOMSE2/RF-NANO11/12/13
Top and bottom
# Component Description
1 Left button Press to perform standard left mouse actions such as selecting items and
opening programs.
2 Forward Button Press to go to the next page in a Web browser.
3 Back Button Press to go to the previous page in a Web browser.
4 LED indicator Indicates the current mouse state.
• Off—The mouse is turned off.
• Green—The mouse is turned on and the battery has a charge.
• Flashing red—The battery charge is low and the battery needs to be
replaced.
5 Right button Press to perform standard right mouse actions such as opening popup menus
or viewing help information.
6 Scroll wheel Roll the scroll wheel to move the screen image up or down.
If you press down on the scroll wheel, a four-way icon appears on the screen.
Then move the mouse up, down, left, or right to scroll.
7 Power switch Slide to turn the mouse on or off.
8 Optical sensor Detects mouse movements and sends signals to the laptop to move the
mouse pointer on the screen.
6
5 1
2
3
4
7
8
