INTRODUCTION
TW144 01/11
Introduction Section 2-3
© 2011 Alamo Group Inc.
INTRODUCTION
Equipment Specifications
Cutting Width
144”
540 PTO
Transport Width
151”
Blade Tip Speed
Overall Width
151”
Center
15,523 FPM
Overall Length
130” (Lift), 168” (Pull)
Cutting Height
2-12”
Gearbox Rating
HP Required (min)
70 HP (Lift), 55 HP (Pull)
Center Gearbox
120 HP
Cutting Capacity (max)
2”
Outboard Gearbox
100 HP
Weight
2142 lbs
LImited Warranty
5 Year
Tongue Weight
1100 lbs.
Driveline Size
CAT 4
Limited Warranty
1 Year
