EB4300
Fig.2 ENGINE GROUP
Key#
Part Number
Description
Q'ty
1
1490-12113
Cylinder
1
2
2756-12210
Gasket, base
1
3
3495-12280
Bolt
4
4
1484-13160
Insulator
1
5
2756-13120
Gasket
1
6
2756-13130
Gasket
1
7
0263-90535
Screw
2
8
1491-32110
Cover
1
9
2750-12520
Bolt
2
10
2756-15100
Muffler ass’y
1
11
1421-15120
Arrester
1
12
2750-15210
Gasket
1
13
2750-15160
Bolt
2
14
2750-15170
Bolt
1
15
2756-21100
Crankcase comp
1
16
2756-21140
Gasket
1
17
2810-21240
Bearing
3
18
1520-21220
Oil seal
1
19
1400-21220
Oil seal
1
20
01252-30530
Bolt
4
21
04065-03515
Snap ring
1
22
2750-21210
Cover
1
23
1565-72211
Bolt
1
24
1483-41111
Piston
1
25
1400-41220
Ring
2
26
1490-41310
Piston pin
1
27
3350-41320
Snap ring
2
28
1400-41410
Bearing
1
29
2616-41510
Washer
2
30
2756-42000
Crankshaft comp
1
31
1300-42410
Shim
0~1
32
1400-43230
Nut
2
33
1000-43240
Key
1
34
2750-71110
Rotor
1
35
2750-71200
Coil ass’y
1
36
2750-72150
Bolt
2
37
1900-72111
Cap
1
38
1900-72120
Spring
1
39
5500-72130
Grommet
1
40
1497-73110
Spark plug
1
(Champion RJ6C)
41
2756-71220
Cap
1
42
2756-73200
Cord comp
1
43
1487-75100
Recoil ass’y
1
44
1180-75221
Spring
1
45
1487-75120
Reel
1
Key#
Part Number
Description
Q'ty
46
1487-75140
Dog
1
47
1861-75150
Washer
1
48
1483-75270
Screw
1
49
1487-75160
Retainer
1
50
1487-75170
Washer
1
51
1400-75160
Rope
1
52
1400-75170
Knob
1
53
1487-75211
Pulley
1
54
3460-75510
Bolt
4
55
2756-75610
Label
1
56
3407-81000
Carburetor
1
57
3407-82102
Body ass’y
1
58
3407-82130
Plate
1
59
3407-82140
Lever
1
60
2630-33610
Screw
1
61
1487-82200
Cover ass’y
1
62
1487-82210
Knob
1
63
1491-82311
Element
1
64
1484-82510
Plate
1
65
0263-90560
Screw
2
66
1491-82352
Screen
1
67
1491-82360
Screw
1
68
1133-82060
Label
1
69
2750-21510
Bolt
6
101
2756-05010
Short block
OP
102
2756-06010
Gasket kit
OP
103
2750-96100
Puller ass’y
OP
104
3350-96220
Stopper
OP
105
3350-96230
Guide
OP
106
2750-96240
Gauge
OP
❲
