RedMax CHTZ2401L User Manual
Page 49
49
Key#
Part Number
Description
Q'ty
1
848-F08-1210
CYLINDER COMP.
1
2
848-F08-12C0
• COVER, TR-S
1
3
848-F08-12D0
• COVER, TR-F
1
4
848-F08-12E0
• GASKET, TR
2
5
848-814-1000
• BOLT
4
6
848-F01-12B0
GASKET, base
1
7
4820-12130
BOLT TORX
4
8
848-F08-14A1
INSULATOR
1
9
848-F08-14B2
GASKET, insu
1
10
848-F08-14C0
GASKET, carb
1
11
T4950-52001
BOLT TORX
4
20
848-F01-2111
CRANKCASE COMP.
1
21
T1551-21141
GASKET, case
1
22
06030-06001
BEARING
2
23
4810-21210
SEAL
1
24
1850-21220
SEAL
1
25
04065-02812
RING
1
26
4820-13180
BOLT TORX M5xL20 T27
3
30
848-F08-41A2
PISTON
1
31
848-8C3-4101
RING
2
32
1600-41310
PIN
1
33
1260-41320
RING
2
34
T1551-41410
BEARING
1
35
1101-41340
WASHER
2
36
848-F01-4202
CRANKSHAFT COMP.
1
37
1650-43230
NUT M8xP1.0
1
38
1000-43240
KEY
1
40
848-F0G-7110
ROTOR ASSY
1
41
2841-71120
• PAWL
2
42
2850-71140
• SCREW
2
43
2850-71151
• WASHER 5x10x10
2
44
T1501-71130
• SPRING
2
45
848-F0G-7120
COIL ASSY
1
46
4810-72111
• CAP
1
47
848-F08-71G0
• SPRING
1
48
848-8MX-0700
• TUBE
1
49
1260-71261
SPACER
2
50
4820-72150
BOLT TORX M4xL16 T27
2
60
848-F0G-8101
CARBURETOR ASSY
1
61
848-F60-0630
• REBUILD KIT
1
62
1850-81450
• • BODY ASSY
1
63
4810-06021
• • GASKET KIT
1
64
1850-81490
• BODY
1
65
1850-81520
• COVER
1
66
1751-81510
• PUMP
1
69
1751-81130
• RING
1
70
1881-81140
• SWIVEL
1
71
1752-81110
• SCREW
2
72
5500-81120
• BRACKET
1
73
1751-81180
• NUT
1
74
1918-81170
• SCREW
1
75
1850-81530
• SCREW
4
76
5500-81160
• WASHER
1
77
4820-15310
BOLT TORX M5xL50 T27
2
78
1950-86120
CLIP
1
79
4500-81910
COVER
90
848-F0G-15A0
MUFFLER
1
91
4820-15310
BOLT TORX M5xL50 T27
2
Key#
Part Number
Description
Q'ty
92
848-F0G-15C0
GASKET, muff
1
93
848-F00-15D1
PLATE
1
94
4820-12350
BOLT TORX M5xL10 T27
2
100
848-F01-31A1
COVER, engine
1
101
848-F01-31B1
DEFLECTOR
1
102
4820-32120
BOLT TORX
2
110
848-EA0-5110
SHOE COMP.
1
112
T1700-51220
• SPRING
1
113
1140-51230
WASHER
2
114
1970-51241
WASHER
2
115
848-F01-51H0
SCREW
2
116
848-F01-51G0
PLATE, clutch
1
117
2850-55211
WASHER
1
120
848-F01-7210
CORD COMP.
1
121
3699-91867
SPARK PLUG NGK CMR7H
1
122
4810-72120
GROMET
1
130
848-F01-7511
RECOIL ASSY
1
132
T1512-75120
• REEL
1
133
T1501-75130
• SPRING
1
134
1850-75151
• SCREW
1
135
T1501-75160
• ROPE
1
136
3330-75421
• KNOB
1
137
4820-32120
BOLT TORX
4
140
848-F01-8310
BODY ASSY
1
141
T1501-82130
• PLATE, choke
1
142
T1501-82140
• LEVER
1
143
2630-33610
• SCREW
1
144
848-F01-83F0
ELEMENT
1
145
T1501-82180
SCREEN
1
146
T1501-82200
COVER ASSY
1
147
5500-82221
• KNOB
1
150a
848-F01-8502
TANK ASSY
1
150b
848-F0L-8500
TANK ASSY (CA Only)
1
151
T1501-85120
• PACKING
2
152
T1015-85202
• CAP ASSY
1
153
4500-85300
• • HOLDER ASSY
1
154
4500-85220
• • PACKING
1
155
5601-85260
• • FILTER
1
156
4820-85260
• • STOPPER
1
157
848-F01-8530
• PIPE COMP.
1
158
3302-85400
• FILTER
1
159
1260-85460
• CLIP
1
160
4820-32120
BOLT TORX
3
180
848-F0G-90C0
LABEL, recoil
1
181
T1551-31130
LABEL, cover
1
220
848-F02-8311
BODY ASSY (OPTION)
1
221
T1512-82130
• PLATE, choke (OPTION)
1
222
T1600-82140
• LEVER (OPTION)
1
223
T1108-82190
• SCREW (OPTION)
1
224
T1513-82120
• PACKING (OPTION)
1
225
T1513-82170
ELEMENT (OPTION)
1
226
848-F02-83K0
PLATE (OPTION)
1
227
848-F3C-8321
COVER ASSY (OPTION)
1
228
T1108-82220
• KNOB (OPTION)
1
Fig.3 ENGINE UNIT
HTZ2401/CHTZ2401/HTZ2401-CA/CHTZ2401-CA
(S/N 60100000 and up)
HTZ2401-L/CHTZ2401-L/HTZ2401-L-CA/CHTZ2401-L-CA (S/N 60100000 and up)
