InStALLAtIon FLEXIBILIty
no FIREpLACE, no pRoBLEM
not all households have an existing masonry fire place, but this doesn’t mean you can’t install a Rinnai flame fire. Royale Inbuilt,
Slimfire 25 and constellation models can be installed into decorative fireplaces as demonstrated in the photos below.
due to it’s advanced flue system design, the Aspiration can be installed just about anywhere, whether a fireplace exists or not.
tHE FInISHIng toUCH
BEFoRE BUILD A FRAME SLIp In tHE ZERo BoX
DRop In tHE FLUE pLAStER AnD pAInt
Height Width Depth Zero Box Order Code
Royale Inbuilt 745mm 810mm 440mm (min.)
ZEROR1 (Metallic Black)
ZEROR2T (Titanium)
Slimfire 25 675mm 685mm 370mm (min.)
ZEROS (Metallic Black)
ZEROS2 (Stainless Steel)
Aspiration 600mm 860mm 450 or 500mm* Not Required
Constellation
665mm +
Hearth Height
1000mm 450mm Not Required
FRAME DIMEnSIonS
*Depth depends on flueing option, see
installation instructions for full details
Royale Inbuilt in decorative Fireplace
