Optional Ports
Up to 2 Additional Ports
Fast 10/100BaseTX or 10/100BaseFX
Fiber Optical (MMF/SMF)
Multiple Fiber Connector Types
Integrated Power Supply
Universal high-voltage range:
88-300VDC or 85 - 264VAC
Popular low voltage DC ranges: 24VDC
(9-36VDC), 48VDC (36-59VDC)
Dual Isolated DC power inputs
Fast Ethernet Ports:
6 - Fast Ethernet Ports
(10/100BaseTX)
Critical Alarm Relay
Form-C failsafe contact relay:
1A@30VDC
RuggedSwitch™ RS900W
Rugged Construction
20 AWG. galvanized
steel enclosure
Conformal coating
(optional)
Operating Temperature
-40 o C to +85 o C
No Fans
Mounting Options
Din Rail
Panel Mount
Hazardous Location
Certification
Class1, Division2
www.RuggedCom.com 2 RuggedWireless™ RS900W
RuggedWireless TM RS900W
Wireless Ethernet with Integrated 8-Port Managed Switch
Antenna
Standard 3dBi
Various antenna option
packages available
Wireless Specifications
IEEE 802.11b/g compliant provides simultaneous support for
both IEEE802.11b and IEEE802.11g wireless clients.
Can be configured as an access, client or bridge device
Antenna type: Removable, upgradeable 3dBi Antenna with
R-SMA (male) connector
Operating channels/frequency-range:
11 channels, 2.400 - 2.4720 Ghz (US, Canada)
13 channels, 2.400 - 2.4835 Ghz (ETSI)
14 channels, 2.400 - 2.4970 Ghz (Japan)
Data rates:
IEEE 802.11b: 11/5.5/2/1 Mbps with automatic failback
IEEE 802.11g: 54/48/36/24/18/12/9/6 Mbps with
automatic failback
Modulation technology:
IEEE 802.11b: DSSS over CCK (11/5 Mbps), DQPSK
(2 Mbps), DBPSK (1 Mbps)
IEEE 802.11g: OFDM over 64QAM, 16QAM, QPSK, BPSK
Transmit power:
IEEE 802.11b: 20dBm nominal @ 11 Mbps
IEEE 802.11g: 16dBm nominal @ 54 Mbps
Receiver sensitivity:
IEEE 802.11b: -88dBm @ 11 Mbps with 8% FER
IEEE 802.11g: -74dBm @ 54 Mbps with 10% FER
