Subaru Robin Power Products EX40 User Manual
Page 27
EX40 -
27
- 08-08
Ref. Part
Number Description
Qty Remarks
To-From Fig.
SECTION 7
ELECTRIC DEVICE GROUP - ELECTRIC STARTER
120 279-70502-00 Starting
Motor
Ay
1
710
-1 209-70550-08
Yoke
Cp
1
710
-2 209-70551-08
Brush
4
710
-3 209-70545-08
Brush
Spring
4
710
-4 209-70530-08
Brush
Holder
1
710
-5 209-70552-08
Insulator
1
710
-6 209-70554-08
Armature
Ay
1
710
-7
209-70521-08
Over Running Clutch Cp
1
710
-8 279-70550-08
Housing
Cp
1
710
-9 209-70511-08
Bush
1
710
-10 209-70505-18 Frame
Cp
1
710
-11 209-70510-08 Bush
1
710
-12 209-70525-08 Lever
1
710
-13
279-70515-18
Magnet Switch Cp
1
710
-14 234-70555-08 Pinion
Stopper
1
710
-15 209-70557-18 Snap
Ring
1
710
-16 209-70558-08 Through
Bolt
2
710
-17 949-29970-02 Nut
2
710
-18 209-70560-08 Nut
1
710
-19 107-70652-08 Spring
Washer
1
710
-20 211-70584-08 Nut
1
710
