Subaru Robin Power Products EX40 User Manual
Page 11
EX40
- 11 -
08-08
Ref. Part
Number Description
Qty Remarks
To-From Fig.
SECTION 3
INTAKE and EXHAUST GROUP
10 20B-31601-01
Camshaft
Cp
1
300
25 20B-35101-03
Pin,
camshaft
1
300
27 024-00700-20
O
ring
1
300
34 005-19041-00
Pin,
spring
2
300
35 277-36401-03
Release
lever
1
300
37 20B-36501-03
Clip
1
300
38 277-38702-03
Return
Spring
1
300
60 246-33611-03
Valve
Spring
2
300
70 246-33711-13
Spring
Retainer
2
300
80 20B-33401-H3
Intake
Valve
1
300
90 20B-33501-H3
Exhaust
Valve
1
300
95 246-35501-03
Collet
Valve
4
300
150 20B-35601-H1 Timing
Chain
1
300
160 277-36911-03 Tentioner
1
300
163 277-37101-03 Spring,
tentioner
1
300
166 277-36902-03 Pin,
tentioner
1
300
170 277-36913-13 Chain
Guide
1
300
200 20B-35001-01 Pin,
rocker
1
300
210 003-13060-00 Clip
1
300
220
20B-36101-00
Rocker Arm Ay, intake
1
300
225
20B-36102-10
Rocker Arm Ay, exhaust
1
300
230 014-90500-20 Adjust
Screw
1
300
231 014-90500-20 Adjust
Screw
1
300
240 017-00500-30 Nut
1
300
241 017-00500-30 Nut
1
300
290 011-00600-20 Flange
Bolt
1
300
310 20B-30101-J2 Muffl er
1
300
315 20B-37001-01 Defl ector Cp
1
300
317 015-00400-60 Tapping
Screw
3
300
320 20B-34201-11 Muffl er Cover Cp
1
300
340 20B-35201-03 Gasket,
muffl er
1
300
350 980-20082-80 Flange
Nut
2
300
361 011-00600-10 Flange
Bolt
5
300
365 011-00803-20 Flange
Bolt
1
300
