M300/ M301 Re:connect
6
Connection formats
In detail, the following
connections can be made with
the video sources 1 - 6:
Connection Video Format Audio Format
Input Output Input Output
Video 1
YC
CVBS YC
CVBS Analogue stereo Analogue stereo
Video 2
YC
CVBS YC
CVBS Analogue stereo Analogue stereo
Video 3
YC
CVBS - Analogue stereo -
Video 4
YC
CVBS - Analogue stereo -
Video 5
YC
CVBS
RGB
YCrCb - Analogue stereo
Digital stereo
Digital 5.1
(Coaxial)
Video 6
YC
CVBS
RGB
YCrCb - Analogue stereo
Digital stereo
Digital 5.1
(Optical)
Monitor
YC
CVBS
RGB
YCrCb
SCART
Analogue stereo Analogue stereo
L
YC = S-VHS Signal
CVBS = Normal video signal , also known as FBAS
RGB = Component signal with Red, Green, Blue
Y Cr Cb = Colour difference signal, also shown with Y P
R
P
B
You will find a more detailed description in the section Video mode in
the chapter DVD MKII-Module.
