Royal Sovereign RSL-2701 - Manual (Page 25)

RSL-380
P NO. DATE
1 013LR3069A BASE-FRONT SPCC 1.5T
2 026004005A FOOT NATURAL RUBBER
3 013LR3070A BASE-REAR SPCC 1.5T
4 350LR3008C PCB-MAIN ASS'Y EU,AU,KR,CH,UK FR-4
4-1 350LR3008D PCB-MAIN ASS'Y CUL,JAP FR-4
5 34000S009B POWER TRANSFORMER(EU,AU,KR,CH,UK) 220～240V/50～60Hz
5-1 34000S009C POWER TRANSFORMER(JAP,CUL) 100-120V/50～60Hz
6 23200X001A SUPPORT-PCB NYLON 66
7 021CR3001A KNOB-CUTTER,C ABS PA-765 UL94 V-0 PANTON 431C
8 140LR3001A HOLDER-CUTTER,C ABS PA-765 UL94 V-0 PANTON 431C
9 213LR4001A CUTTER-CROSS STS420 J2 1T
10 013LR3035A PLATE-MIDDLE SPCC 1.0T
11 013LR3067A FRAME-L SPCC 3.0T
12 141LR4017A BRACKET-PRESSURE SPCC 2.0T
13 141LR4035A PLATE-DU BUSH SPCC 2.0T
14 141LR4054A BRACKET LIMIT SWITCH SPCC2.0
15 36400X014B MICRO S/W DECO VP-531A-2H
16 021LR4001A LIMIT SWITCH COVER PP
17 013LR3068A FRAME-R SPCC 3.0T
18 133LR3001A ROLLER-LAMI STPG ORANGE
19 122LR4044A BUSH-ROLLER LAMI,UP FTG70Cu3-35
20 12200X028A DU BUSH
Φ25*20 FLANGE
21 122LR4050A BUSH-ROLLER LAMI,LO ASS'Y FTG70Cu3-35
1) 12200X027A DU BUSH
Φ25*10 FLANGE
23 133LR3004A ROLLER-PULL，LOW S45C ORANGE
23-1 133LR3005A ROLLER-PULL，UP S45C ORANGE
24 122LR4043A BUSH-ROLLER PULL,UP S45C Cu+Ni+Cr
25 12200X030A DU BUSH Φ10*20 FLANGE
26 122LR4047A BUSH-ROLLER PULL,LO FTG70Cu3-35
27 12200X029A DU BUSH
Φ10*10 FLANGE
28 120LR3020A SHAFT-FILM S45C Cu+Ni+Cr
29 12200X002A DU BUSH
Φ10*10 FLANGE
30 023LR4004A KNOB-TENSION SIXN2 （PF+BRASS）403 BRAMA
31 120LR4006A SHAFT-TENSION S45C Cu+Ni+Cr
32 141LR4025A PLATE-HOLDER SHAFT SPCC 2.0T 20081013
33 140LR4008A HOLDER-SHAFT FILM S45C Cu+Ni+Cr
140LR4039A 20081013
34 12200X033A BEARING-RADIAL TRUST NTB 17*30
35 147LR4008A PAD-TENSION LEATHER 1.5T
36 124LR4003A CORE-24 AL6063
37 015LR2002A IDLE BAR S45C Cu+Ni+Cr
015LR2010A 20080618
38 12200X032A DU BUSH
Φ12*10 FLANGE
39 210004002A MOTOR-MAIN DC24V
21000S038A 20100419
40 131LR4021A SPROCKET-MOTOR FTG70Cu3-35 15Z
131LR4034A 20080728
41 223LR3001D HEATER ASS'Y
FCHW1 20.2Ω EU,AU,CH,KR
SVC Parts List
No. Part No. Part Name Spec.
CHANGING REMARK
44
