Rockford Fosgate Prime R150-2 - Manual (Page 10)

10
S
PECIFICATIONS
MODEL- PRIME R150-2
Continuous Power Rating (RMS) - Measured at 14.4 Battery Volts
4 Load Per Channel 50 Watts x 2
2 Load Per Channel 75 Watts x 2
4 Load Bridged 150 Watts x 1
Dimensions: Height 2.40" (6.10cm)
Width 7.67" (19.49cm)
Length 11.54" (29.30cm)
Amplifier Fuse Rating (Amp) 20A ATC
Battery Fuse Rating (Amp) External (Not Supplied) 20A
“A” Weighted Signal to Noise Ratio
Referenced to 1 Watt into 4 ohms
≥70 dB
“A” Weighted Signal to Noise Ratio
Referenced to rated output into 4 ohms
≥90 dB
Crossover Slope 12dB/octave Butterworth
Crossover Frequency High Pass @ 80Hz, Low Pass variable from 50Hz to 250Hz
Frequency Response 20Hz to 20KHz ±1dB
Signal Voltage Adjustment Range Variable from 150mV to 8V (RCA Input)
Protection Short circuit protection shut downs the amplifier in
case of very low impedance or shorted speaker wires.
Punch Bass Variable from 0dB to +12dB @ 45Hz
Input Impedance 20K ohms
Operating Voltage 9 to 16 Volts DC
Balanced Inputs No
CMRR (Common Mode Rejection Ratio) >40dB @ 1KHz
Damping Factor >200
THD+N (Total Harmonic Distortion + Noise) < 1.0% @ 4 ohm
These specifications are Amplifier Power Standard CEA-2006 Compliant
Specifications subject to change without notice
