RedMax BT250 User Manual

Page 27

background image

Fig.1 DRIVE UNIT BT250 (S/N 40400101 and up)

27 

Key# Part Number

Description

Q'ty

1

BT25-50810

PIPE COMP.

1

2

BT25-50710

DRIVE SHAFT

1

3

BT25-50910

HOUSING ASSY

1

4

BT25-50610

GRIP

1

5

BT25-50510

LEVER ASSY

1

6

BT25-50520

SCREW

1

7

1855-82100

CABLE ASSY

1

8

BT25-80100

TUBE

1

9

BT25-50400

HANDLE ASSY

1

10

BT25-50410

• HANDLE

1

11

0263-90530

• SCREW

3

12 B1181-000504

• NUT

3

13

BT25-80810

GUARD ASSY

1

14

BT25-80840

• GUARD

1

15

01000-69820

• BOLT

1

16

00311-06000

• WASHER

1

17

00217-06000

• NUT

1

18

BT25-80830

• BLADE

1

19

01500-69830

• SCREW

1

20

BT25-90910

PLATE, name

1

21

BT25-90810

SPACER

1

22

BT25-90100

TAP HEAD

1

23

T3002-91190

GOGGLE

1

Key# Part Number

Description

Q'ty
