Rockford Fosgate Prime R1693 - Manual (Page 7)

7
1.00"
(25.40mm)
Verify Scale
Before Using
Template
1.00"
(25.40mm)
6.46"
(164.0mm)
R1653
Mounting
Holes
5.81"
(147.5mm)
R1653 Hole Cutout
S PEAKER M OUNTING T EMPLATE
