7
MOUNTING THE PHONE
You can place the phone on a desk or
table, mount it on a standard wall plate,
or mount it directly on a wall.
Select a location that is:
• near an AC outlet
• near a modular phone line jack
• out of the way of normal activities
Notes:
• Your telephone connects directly to
a modular phone line jack. If your
phone line jack is not modular, you
can update it yourself, using jacks
and adapters available from your lo-
cal RadioShack store. Or, you can
let the telephone company update it
for you.
• The USOC number of the jack to be
installed is RJ11C for a baseboard,
or RJ11W for a wall plate.
Caution: The supplied AC adapter was
designed specifically for your System
999. Use only the supplied adapter.
1. Remove the mounting bracket by
pressing
On a Desk
2. Plug one end of the supplied long
modular cord into the TEL. LINE jack
on the back of the phone.
3. Plug the cord’s other end into a
modular phone line jack.
4. Insert the tabs on the narrow end of
the desk top stand into both upper
slots. Then snap both of the bottom
tabs of the stand into place.
5. Insert the supplied AC adapter’s
barrel plug into the DC 9V jack on
the back of the phone.
Illustration,
connecting long line cord
Illus. showing desk top stand
Illus. showing 9V AC jack .
