7
5. The Console (4) requires four “D” batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the exercise cycle has been
exposed to cold temperatures, allow it to warm
to room temperature before inserting batteries
into the Console. If you do not do this, the con-
sole displays or other electronic components
may become damaged. Remove the battery cover
from the back of the Console. Next, insert four bat-
teries into the battery compartment; make sure that
the batteries are oriented as shown by the dia-
gram inside the battery compartment. Then, reat-
tach the battery cover.
5
4
Batteries
Battery
Cover
Batteries
6. While another person holds the Console (4) near
the Upright (2), connect the console wire harnesses
to the Upper and Main Wire Harnesses (42, 43).
Insert the excess wire downward into the Upright.
Attach the Console (4) to the Upright (2) with four
M4 x 16mm Round Head Screws (80). Be careful
to avoid pinching the Wire Harnesses (42, 43).
2
6
4
80
43
Console
Wire
Harnesses
80
Avoid pinching and
damaging the wires
42
