Roberts Radio RD-12CFM - Manual (Page 13)

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri)
12
Headphone socket
A 3.5mm Headphone Socket located on the right-hand end of your
radio is provided for use with either headphones or an earpiece.
Inserting a plug automatically mutes the internal loudspeaker.
Display backlight
1. The display backlight will be switched on for approximately 12
seconds when any button is pressed. (If using battery source)
2. When your radio is powered by the AC mains the display backlight
will always be switched on.
Line out socket
A 3.5mm Line out socket located on the rear of your radio is provided
for connecting the audio signal to an external amplifier. Inserting a line out
audio cable will not mute the internal loudspeaker. Set the volume control
to minimum if desired.
RD12-CFM Issue 2.pmd 5/25/2005, 11:42 AM 13
