31
MFX 11: WAH MFX 1 2 : RING MODULATOR
Parameter Value Description
Filter Type LPF, BPF
Filter Type
LPF : The wah effect will be applied over
a wide frequency range.
BPF : The wah effect will be applied over
a narrow frequency range.
Manual 0–127
When Control Type is set to “PEDAL,” you
can use this parameter to modify the tonal
character.
Peak 0–127
Adjusts the amount of the wah effect that
will occur in the range of the center
frequency.
Set a higher value to narrow the range to
be affected.
Sens 0–127
When Control Type is set to “TOUCH,”
this adjusts the sensitivity to the volume
used in changing the tone.
Control Type
TOUCH,
PEDAL
Effect Control Types
TOUCH : The tone changes in response
to changes in the volume.
PEDAL : The tone changes according to
the function of the Manual parameter ,
and controller number 4 (CC#4) of MIDI
message
.
Depth 0–127 Depth of modulation
Level 0–127 Output Level
Parameter Value Description
Frequency 0–127
Adjusts the frequency at which
modulation is applied.
Sens 0–127
Adjusts the amount of frequency
modulation applied.
Polarity UP, DOWN
Determines whether the frequency
modulation moves towards higher
frequencies (UP) or lower frequencies
(DOWN).
Low Gain -15–+15dB Boost or cut in the low end
High Gain -15–+15dB Boost or cut in the high end
Balance
D100:0W–
D0:100W Volume balance between the direct sound
(D) and the effect sound (W)
Level 0–127 Output Level
