HARDWARE
4
MULTISTATION PC INSTALLATION AND OPERATIONS MANUAL
Hardware
Front
Remote
user
module
Rear
Remote
user
module
PCI card
Figure 1. Hardware
Connectors:
Front
§ MiniDin-6 PS/2 keyboard
§ MiniDin-6 PS/2 mouse
Rear
§ RJ45 CAT5 cable connection
§ HD15M
VGA monitor connection
PCI card
§ RJ45 CAT5 cable connection
§ Dip Switch Configuration setting switches
