3
8. Align each speaker’s mounting
holes and mounting bracket’s
holes with the drilled holes on the
mounting surface and thread a
supplied screw through each hole.
9. Place one small and one large
washer and screw a nut onto the
mounting screw, then tighten all
screws until they are secure.
10. Firmly press the grille onto each
speaker’s mounting bracket.
Note: You can use the supplied
adhesive putty tape to further
secure the grille to the mounting
bracket. Cut off and press a small
piece of putty into each of the four
slots around the mounting
bracket’s surface.
(illus – show the
mounting screw,
aligned with the
speaker’s mounting
holes, the mounting
bracket’s holes, and
the fastening nuts)
(illus showing how to
use the putty)
