GPS-22 Manual
Rikaline
Specifications subject to change without prior notice
Rikaline Marketing Corp.
1. Introduction
1.1 Overview
The Rikaline GPS-22 GPS Receiver is a GPS receiver featuring the revolutionary FirstGPS™
architecture. This complete enabled GPS receiver module provides high position and speed accuracy
performances as well as high sensitivity and tracking capabilities in urban canyon conditions. The solution
enables small form factor package. The GPS-22 delivers major advancements in GPS performances,
accuracy, integration, computing power and flexibility. It is designed to simplify the embedded system
integration process
.
This positioning application meets strict needs such as car navigation, mapping, surveying, agriculture and
so on. Only clear view of sky and certain power supply are necessary to the unit. GPS-22 communicates
with other electronic utilities via compatible dual-channel through RS-232 or TTL and saves critical satellite
data in built–in memory backup. With low power consumption, the GPS-22 tracks up to 8 satellites at a time,
re-acquires satellite signals in 100 ms and updates position data every second.
1.2 Features
The GPS-22 provides a host of features that make it easy for integration and use.
1. Position accuracy in < 3m CEP (50%) or <5m CEP ((90%) without SA (horizontal)
2. Ultra low power: 17mA typical -- tracking at 3.3 Volts, full power
3. High sensitivity: to -173 dBW tracking, superior urban canyon performances
4. Small form factor and low cost solution
5. Ready-to-plug solution. Easily integrated into existing systems
6. On-board RAM for GPS navigation data
7. PPS output (User may have different interval setting from 1 second to 1 minute.
8. Differential capability utilizes real-time RTCM corrections producing < 1 meter position accuracy.
9. FLASH based program memory: New setting is stored permanently.
10. Positioning display status: A LED indicator could be installed to provides users visible positioning status.
LED “ON” when power connected and “BLINKING” when positioned. No more extra device needed.
1.3 FirstGPS Architecture Highlights
1.3.1 Industry Leading GPS Performance
- Builds on high performance FirstGPS TM core
- Satellite signal tracking engine to perform GPS acquisition and tracking functions without CPU
intervention
- High sensitivity: to -143 dBm tracking, superior urban canyon performances
- Position accuracy: < 3m CEP (50%) without SA (horizontal)
- Warm Start is under 42 seconds (90%)
- Hot Start is under 10 seconds (90%)
1.3.2 Low Power
- Ultra low power integrated circuit design, optimized RF and DSP architectures
- Further power saving thanks to 4 different power down mode
1.4 Application
1. Car Navigation
2. Mapping
3. Surveying
4. Agriculture
5. Palmtop, Laptop, PDA
6. Location Based Services enabled devices
7. Asset
management/tracking
8. Handheld receivers
1.5 Technology specifications
1.5.1 Physical Dimension
™
