Rover 2042 User Manual
Page 28
Pull the right side of the belt and place the narrow V side of
10.
the belt into the PTO pulley. See Fig. 7-9.
While holding the belt and pulley together, rotate the
11.
pulley to the left (See Fig. 7-9). Continue holding and
rotating the pulley and belt until the belt is fully rolled into
the PTO pulley.
To place the new belt begin by routing the belt around the
5.
two outer spindle pulleys as shown in Fig. 7-8.
Then route the belt around the two deck idler pulleys as
6.
show in Fig. 7-8.
Reinstall the belt keeper rod loosened earlier.
7.
CAUTION:
Failure to reinstall the belt keeper rod
may result in serious damage to your tractor’s PTO
system.
Remount the belt guards removed earlier.
8.
Re-install the deck making sure the belt remains routed
9.
around the pulleys as instructed.
Figure 7-8
PTO Belt
Rotate
Pulley
Figure 7-9
28
s
ectiOn
7— s
ervice
