27 – 3-channel mono operation, Channel operation – Rockford Fosgate 5.3x User Manual
Page 30
– 27 –
3-Channel Mono Operation
• Front/Rear Gain Controls
set equally to balance the speakers
• Sub Gain Control operates
independently
• Impedance Load for Front bridged channel should be
4
Ω
minimum
• Impedance Load for Rear bridged channel should be
4
Ω
minimum
• Impedance Load for Sub bridged/mono channel should be
4
Ω
minimum
• Front/Rear XCard
set as High-Pass, Low-Pass or Full Range
• Sub XCard can be set for High-Pass, Low-Pass or Full Range
5-Channel Operation
I
N
S
T
A
L
L
A
T
I
O
N
®
®
• Front/Rear/ Sub Gain Controls operate
independently
• Impedance Load for Front/Rear channels should be
2
Ω
minimum
• Impedance Load for Sub bridged/mono channel should be
4
Ω
minimum
• Front/Rear XCard
set as High-Pass, Low-Pass or Full Range
• Sub XCard can be set for High-Pass, Low-Pass or Full Range
GND
REM
L F +
R F +
B +
L R -
R R -
SUB
+
R F -
L R +
R R +
L F -
SUB
–
®
®
390 Watts Total Power
4
Ω
Min.
+
–
4
Ω
Min.
+
–
4
Ω
Min.
–
+
GND
REM
L F +
R F +
B +
L R -
R R -
SUB
+
R F -
L R +
R R +
L F -
SUB
–
®
®
300 Watts Total Power
+
–
4
Ω
Min.
2
Ω
Min.
+
–
2
Ω
Min.
+
–
2
Ω
Min.
–
+
2
Ω
Min.
–
+
