EH035V - 7 - 04-04
SECTION 1 CRANKCASE GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
1 593-10110-00 CYLINDER BLOCK SET 1 100
4 593-15014-00 ROCKER COVER 1 100
5 593-15016-00 GASKET, rocker cover 1 100
6 593-15015-00 CAMGEAR COVER 1 100
7 593-15017-00 GASKET, camgear cover 1 100
8 592-15018-00 CHECK VALVE 2 100
10 592-15010-00 LEAD VALVE 1 100
11 593-15013-00 RETAINER PLATE 1 100
12 593-65005-00 OIL CASE 1 100
13 593-65004-00 GASKET, case 1 100
14 593-65006-00 OIL TUBE 1 100
15 592-65003-00 OIL WEIGHT 1 100
17 593-55002-00-1 BLOWER HOUSING 1 100
18 011-90595-31 SOCKET HEAD BOLT 4 100
19 004-31060-80 SCREW, panhead 1 100
20 003-71060-00 GASKET, fi ber 1 100
21 011-90499-60 SOCKET HEAD BOLT 1 100
22 004-36051-60 SCREW AY 13 100
23 011-90594-70 SOCKET HEAD BOLT 4 100
24 011-90598-60 SOCKET HEAD BOLT 4 100
26 592-65006-00 OIL GAUGE 1 100
27 021-31699-90 GASKET 1 100
28 065-01099-50 SPARK PLUG 1 100
