EH035V - 19 - 04-04
SECTION 7 AIR CLEANER GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
1 593-30010-00-1 CLEANER PLATE AY 1 700
2 593-35007-00-1 AIR CLEANER PLATE 1 700
3 531-65007-01 CHECK VALVE 1 700
4 592-35024-00 CHECK VALVE 1 1 700
5 592-35025-00 PLATE, check valve 1 700
6 593-35016-00 PLATE, separator 1 700
7 592-35035-00 GASKET, separator 1 700
8 592-35022-00-1 CHOKE LEVER 1 700
10 024-01399-70 O RING 1 700
11 024-01599-90 O RING 1 700
12 593-15009-00 BREATHER PIPE 1 700
13 593-35012-00-1 AIR CLEANER ELEMENT 1 700
14 593-35009-00 AIR CLEANER ELEMENT 1 700
15 592-35023-01 PLATE, choke 1 700
16 592-35026-00 PLATE 1 700
17 021-30699-90 GASKET, separator 1 700
18 593-35008-00 AIR CLEANER COVER 1 700
19 593-35021-00 PIPE 1 700
20 056-10800-10 HOSE CLAMP 1 700
21 014-00594-80 SCREW AY 1 700
22 592-35031-00 SCREW 2 700
