Page 14

HD49335NP/HNP
Rev.1.0, Feb.12.2004, page 14 of 29
Absolute Maximum Ratings
(Ta = 25
°C)
Item Symbol
Ratings
Unit
Power supply voltage
V
DD
4.1
V
Analog input voltage
V
IN
–0.3 to AV
DD
+0.3
V
Digital input voltage
V
I
–0.3 to DV
DD
+0.3
V
Operating temperature range
Ta
–10 to +75
°C
Power dissipation
Pt
750
mW
Storage temperature
Tstg
–55 to +125
°C
Power supply voltage
Vopr
2.70 to 3.30
V
Note: AV
DD
, AV
SS
are analog power
source systems
of CDS, PGA, and ADC.
DV
DD
1, DV
SS
1 are digital power source systems of CDS, PGA and ADC.
DV
DD
2, DV
SS
2 are buffer power source systems of ADC output.
DV
DD
3, DV
SS
3 are general digital power source systems of TG.
DV
DD
4, DV
SS
4 are buffer power source systems of H1 and H2.
• Pin 2 multi bonds the DV
SS
1 and DV
SS
2
• When pin 64 is set to Low, pin 41 = STROB output, pin 39 = SUB_SW output
When Hi, pin 41 = Vgate input, pin 39 = ADCK input
Electrical Characteristics
(Unless othewide specified, Ta = 25°C, AV
DD
= 3.0 V, DV
DD
= 3.0 V, and R
BIAS
= 33 k
Ω)
• Items Common to CDSIN and ADCIN Input Modes
Item Symbol
Min
Typ
Max
Unit
Test
Conditions
Remarks
Power supply voltage
range
V
DD
2.70 3.00
3.30 V
f
CLK
hi
20
—
36
MHz
LoPwr = low *
2
HD49335HNP
Conversion frequency
f
CLK
low
5.5
—
25
MHz
LoPwr = high *
2
HD49335NP
V
IH2
DV
DD
3.0
2.25
×
— DV
DD
V
Digital input voltage
V
IL2
0
—
DV
DD
3.0
0.6
×
V
CS, SCK, SDATA
V
OH
DV
DD
–0.5
—
—
V
I
OH
= –1 mA
Digital output voltage
V
OL
—
— 0.5
V I
OL
= +1 mA
I
IH
—
— 50
µA V
IH
= 3.0 V
Digital input current
I
IL
–50 — —
µA V
IL
= 0 V
ADC
resolution RES
10 10
10 bit
ADC integral linearity
INL
—
(2)
—
LSBp-p
f
CLK
= 25 MHz
ADC differential linearity+
DNL+
—
0.3
0.99
LSB
f
CLK
= 25 MHz
*1
ADC differential linearity–
DNL–
–0.99
–0.3
—
LSB
f
CLK
= 25 MHz
*1
Sleep current
I
SLP
–100 0 100
µA
Digital input pin is
set to 0 V, output
pin is open
Standby current
I
STBY
—
3
5
mA Digital I/O pin is set
to 0 V
Notes: 1. Differential linearity is the calculated difference in linearity errors between adjacent codes.
2. 2 divided mode: f
CLK
= 1/2CLK_in
3 divided mode: f
CLK
= 1/3CLK_in
3. Values within parentheses ( ) are for reference.
