At-series cooling unit with filtration, End view front view – Roberts Gorden Combat AT-236 User Manual
Page 4
4
A
K
B
C
E
D
F
SPLIT
FOR
SHIPMENT
H
LIFTING
ANGLES
G
M
L
K
J
J
DISCHARGE
PLENUM
EXTENSIONS (OPTIONAL)
ADDITIONAL
PROPELLER F
AN
SECTION REQUIRED FOR 254, 260, 272
MODELS
PROPELLER F
AN / INLET SECTION
EXTERIOR FIL
TER
RACKS / COILS AND
COIL EXTENSION
END VIEW
FRONT VIEW
DA
DA
RA
RA
RA
RA
DA
DA
AT-Series Cooling Unit with Filtration
IMPORTANT NOTES:
•
All dimensions are in inches.
•
All dimensions are subject to change
without notice.
•
Due to height of unit, additional support is
recommended on top of the unit.
LEGEND
DA = Discharge Air
RA = Return Air
DIMENSIONS
AT-136 AT-148 AT-154 AT-236 AT-242 AT-248 AT-254 AT-260 AT-272
A
60
72
85
90
100
116
145
160
165
B
50
60
72
50
55
60
72
84
90
C
75
85
95
85
85
95
90
90
90
D
48
48
48
48
48
48
48
48
48
E
6
6
6
6
6
6
6
6
6
F
24
24
36
24
30
30
36
36
40
G
10
10
16
6
10
H
.75
.75
.75
.75
.75
.75
.75
.75
.75
J
.75
.75
.75
.75
.75
.75
.75
.75
.75
K
6
6
6
6
6
6
6
6
6
L
3
3
3
3
3
3
3
3
3
M
N/A
N/A
N/A
N/A
N/A
N/A
50
50
50
