12 ST60 Wind & Close Hauled Wind Instrument Owner’s Handbook
Instrument
2.7 in (68 mm)
1.5 in (38 mm)
D6905-1
9.76 in (248 mm)
10.7 in (272 mm)
21.2 in (538.5 mm)
7.4 in (187 mm)
Approx 16.8 in (426 mm)*
2.76 in (70 mm)
Wind Vane
Rotavecta
*Exact Rotavecta height is dependent
on mounting method. Wind transducer dimensions
110mm (4.33in) 24mm
(0.95in)
15mm
(0.6in)
90mm (3.54in)
diameter
115mm (4.53in)
123mm (4.85in) 6.2mm
(0.25in)
35mm
(1.4in)
90mm (3.54in)
diameter
123mm (4.85in)
D5785-2
ST60 instrument dimensions
With standard
bezel
With low
profile bezel
