8 Connecting Inputs
ˆ
Connecting Inputs
LOW-LEVEL INPUTS
You can connect your auto sound system’s
low-level line out jacks to the amplifier’s low-
level line in jacks.
If your auto sound system does not have
low-level line out jacks, see “High-Level
(Speaker Wire) Inputs” on Page 9 to connect
your amplifier.
Note: For the best results, use shielded au-
dio cables (not supplied) available at your lo-
cal RadioShack store.
1. Temporarily place the amplifier as close
as possible to the selected mounting
location.
2. If your auto sound system has four separate line out jacks, connect the auto sound system
to the amplifier.
Left Rear
Right Rear
Auto Sound System
CH 4 CH 1 CH 2 CH 3
Right Front
Left Front
