Subaru Robin Power Products EX13 User Manual
Page 9
EX130D52090
- 9 -
10-06
REF.
PART NO.
DESCRIPTION
QTY. REMARKS
FROM-TO
FIG.
SECTION 2
CRANKSHAFT GROUP
10
276-21201-21
CRANKSHAFT
1
SAE Taper
200
50
018-01400-20
FLANGE NUT
1
M14X1.5X28DX12H
200
70
032-30300-10
WOODRUFF KEY
1
3BX6HX16D
200
310
276-22501-10
CONNECTING ROD AY
1
80.2CDX25B 30D-13D
200
276-22502-00
CONNECTING ROD AY
1
0.25 U.S.
200
320
277-23001-03
CONNECTING ROD BOLT
2
M6X1.0X13DX33L
200
350
276-23301-13
PISTON PIN
1
13DX9DX44L
200
360
276-23401-H3
PISTON
1
STD (58DX35H)
200
276-23403-H3
PISTON
1
0.25 O.S.(58DX35H)
200
276-23404-H3
PISTON
1
0.50 O.S.(58DX35H)
200
370
276-23501-17
PISTON RING SET
1
STD(58D) OIL 3 PIECE
200
276-23502-17
PISTON RING SET
1
0.25 O.S. OIL 3 PIECE
200
276-23503-17
PISTON RING SET
1
0.50 O.S. OIL 3 PIECE
200
380
215-25004-03
CLIP
2
14.1DX1.2D
200
