GROUP INDEX
Group Name Page
CRANKCASE GROUP ............................................................................... 6
CRANKSHAFT GROUP ............................................................................. 8
INTAKE and EXHAUST GROUP .............................................................. 10
GOVERNOR GROUP .............................................................................. 18
COOLING and STARTING GROUP ......................................................... 22
FUEL, LUBRICANT GROUP .................................................................... 26
CARBURETOR GROUP .......................................................................... 28
ELECTRIC DEVICE GROUP .................................................................. 32
ACCESSORY GROUP ............................................................................. 38
SYMBOL DESCRIPTION
AY ........................... ASSEMBLY
CP ........................... COMPLETE
EX ........................... EXPORT (from Japan)
FIG. ......................... FIGURE
FR. .......................... FRONT
" .............................. INCH
INCL. ...................... INCLUDE
~L ............................ LITER
L= ........................... LENGTH (in. mm)
L.H. (LH) ................. LEFT-HAND SIDE
MECH ..................... MECHANICAL
NO (NON) ............... NONE
OPT......................... OPTIONAL
O.S. ........................ OVER SIZE SYMBOL DESCRIPTION
P= ........................... PITCH (in mm)
P.T.O. (PTO) ........... POWER TAKE OFF
REF. ........................ REFERENCE
R.H. (RH) ................ RIGHT HAND SIDE
RR. ......................... REAR
STD. ....................... STANDARD
SW .......................... SWITCH
T= ........................... THICKNESS (in mm)
UN .......................... UNIT
U.S.......................... UNDER SIZE
~V ........................... VOLTAGE
~W .......................... WATT
W/ ........................... WITH
W/O ........................ WITHOUT
INDEX OF DESCRIPTION SYMBOLS
