3. Hardware interface

3.1 Dimension

Size: 83.0(H) x 47.5(W) x 14.5(D) (mm)

3.27"(H) x 1.87"(W) x 0.57"(D).

3.2 Hardware Interface

The GPS-6021-X6 includes an antenna in a unique style gadget. It is a type I CF card device, which

can be used with both type I and type II CF slot. Simply put it into a CF card slot or insert it into PCMCIA slot
through a PCMCIA adapter of any type of PC with Windows OS. The interface is through a standard 50-pin
PCMCIA connector with RS-232 level.

3.3 Connector

1) Standard 50-pin CF female connector.
2) Optional active antenna female MC Card connector.

3.3.1 Function definition of CF card connector

Please download detail at http://compactflash.org/specdl1.htm

3.4 Accessories

3.4.1 Active Antenna

A-10302-MC Active Antenna with 2 meter 180 MC Card connector
A-10305-MC Active Antenna with 5 meter 180 MC Card connector
