Xtrac High Sensitivity GPS-6021-X6 Operating Manual
Rikaline
Rikaline International Corp. 14F, 171, Chen-Gong Road, SanChung City, Taipei 241, Taiwan
Tel: ++886 2 8973 1899 Fax: ++886 2 8973 1896 E-Mail: [email protected] Web: www.rikaline.com.tw
3
0. Quick Use
0.1 Check GPS Package
0.1.1 Standard Package
GPS-6021-X6 (GPS Receiver) + CD + Warranty Card + quick installation reference.
0.1.2 Optional Package
The shop may bundle different accessories for you as follows:
1. Active Antenna
2. PCMCIA Adapter
3. PDA Holder
4. Software (Navigation Software + Digital Map)
5. Others
0.2 Check Accessories
1. A-10302-M Active antenna is used when GPS-6020 can not get good signal. We do not recommend
you to connect it all the way. If you got signal from both the GPS-6020 main unit and the active
antenna, the signal strength could be less than they have to be.
2. The GPS-6021-X6 is design as plug in and use. You do not need any driver for CF slot.
3. GPS-6020 is CF type I device. It could be used for CF type I and II. When you put GPS-6020 in CF
type II slot, please pay attention not to damage the CF slot or the GPS.
4. When you connect GPS-6021-X6 with your PC (Webpad PC, Tablet PC, Laptop PC or other PCs)
through a PCMCIA adapter, you need a driver which is included in the CD.
0.3 Connect GPS-6021-X6 to your machine.
Turn on your machine and execute the navigation software.
0.4 Manufacturing Default
1. Sentence: GGA, GSA, GSV, RMC, VTG
2. Baud Rate: 4800
3. Datum: WGS84
4. DGPS: Not connected
0.5 Important Information
1. First time use: please wait a little bit longer to have the unit got position fix for minimum 1 minutes.
Then you may experience the high sensitivity of using GPS-6021-X6.
2. Active Antenna:
a// The connector of the active antenna might be fragile. Be sure to place it correctly when plug in and
un-plug it.
b// If your device can not receive GPS signal when you un-plug the active antenna, please plug in
and un-plug again. Because there is a small switch inside the small MC card connector in the
GPS unit, some time it does not retain to its normal position when you un-plug the active antenna.
3. Operating temperature range from -40
o
C to +85
o
C (internal temperature)
0.6 Accessories
1. Active Antenna: A-10302-MC, with 2 meter cable, MC card connector.
2. Active Antenna: A-10305-MC, with 5 meter cable, MC card connector.
3. PDA Holder: Please refer page 11.
