* Standard Hardware Item – May Be Purchased Locally
** Parts available at your local Subaru Robin dealer
KEY P/N DESCRIPTION QTY
1 661501001 * Screw
(1/4-20 x 2 in., Torx Truss Hd.) ...................6
2 661505005 * Bolt (M8 x 36 m m, Hex Hd.) ......................4
3 661505003 * Bolt (M8 x 50 m m, Hex Hd.) ......................4
4 660739002 * Bolt (5/16-24 x 22 m m) ..............................4
5 661555001 * Bolt (M4 x 0.7 x 12 m m).............................3
6 660592005 * Bolt (1/4 x 42 m m, Pan Hd.) ......................2
7 660391002 * Bolt (M8 x 20, Hex Hd.) .............................2
8 308662001 Filter Screen ...............................................1
9 678016006 * Lock Nut (1/4 in.) .....................................12
10 678774001 * Lock Nut (M8 x 1-1/4 in.) ...........................8
11 678610002 * Lock Nut (M4) ............................................3
12 638128004 * Washer (1/4 in.) ..........................................9
13 638275002 * Washer (1/2 in.) ..........................................2
14 518724002 * Washer (D20 x D8 x 5t) ..............................2
15 518932001 Handle Tube Cap .......................................4
16 308941001 Handle Assembly
(Inc. Key Nos. 15 and 63) ..........................1
17 940779003 Performance Label ....................................1
18 308938004 Right Frame Assembly...............................1
19 940617012 Engine Quick Start Label ...........................1
20 308939004 Left Frame Assembly .................................1
21 638385006 Engine Plate ...............................................1
22 638671001 Face Plate ..................................................1
23 678143001 Bar .............................................................1
24 661503002 * Bolt (1/4 x 19 m m, Hex Hd.) ......................2
25 940726009 Trigger Handle Logo Label ........................1
26 561307001 Rubber Foot ...............................................2
27 940780001 Pump Quick Start Label ............................1
28 308909003 Foot Assembly
(Inc. Key Nos. 9, 12, 24 and 26) ................1
KEY P/N DESCRIPTION QTY KEY P/N DESCRIPTION QTY
RD80746/RD80947 Gasoline Pressure Washer
29 518931001 Bottom Wand Holder .................................1
30 940786002 Wand Label (Max Rating) ...........................1
31 940654058 Trigger Handle Warning Label
(French/Spanish) ........................................1
32 518926001 Bottle Bumper............................................1
33 308113002 3/8 in. Ouick Connect
(Female Coupler)........................................1
34 518470001 TRV Spout..................................................1
35 678169002 Thermal Release Valve ...............................1
36 309515001 Pump .........................................................1
37 309590001 ** SP170 Engine (RD80746) ..........................1
309590002 ** SP170 Engine (RD80947) ..........................1
38 308451003 Wheel (12 in. x 3 in.)...................................2
39 620598001 Axle ............................................................2
40 570728001 Pump Hose ................................................1
41 570728002 Tank Hose ..................................................1
42 570728003 Bottle Hose ...............................................1
43 518391001 Filter (Injection Hose) .................................1
44 310650001 Soap Tank Cap ..........................................1
45 940678016 Data Label..................................................1
46 308283003 Filter ...........................................................1
47 308985002 Outlet With Filter ........................................1
48 310658003 Soap Tank Assembly
(Inc. Key Nos. 46-47) .................................1
49 308910001 Release Pin ................................................1
50 308350001 Hook-And-Loop Strap ...............................1
51 678406004 Connector Pin (1/4 in.) ...............................2
52 678238001 Hitch Pin ....................................................2
53 308531002 Bungee Cord With Hooks ..........................1
54 308835003 High Pressure Hose ...................................1
55 638637002 Spring Clip .................................................1
56 570727004 Nozzle Holder ............................................1
57 308697010 Nozzle, 0° (Red) .........................................1
58 308698010 Nozzle, 15° (Yellow) ...................................1
59 308699010 Nozzle, 25° (Green) ....................................1
60 940693003 Handle Release Label ................................1
61 310660002 Dual Power Soap Nozzle ..........................1
62 678148002 Nozzle Cleaning Tool .................................1
63 570733001 Bumper ......................................................2
64 308494004 Spray Wand (21 in.)....................................1
65 120950013 Trigger Handle Assembly ...........................1
66 120900031 Wand Holder Kit.........................................1
67 120900032 3-Way Valve Kit ..........................................1
68 513122001 Auxiliary Handle .........................................1
69 940971011 Engine Oil (Hang Tag) ................................1
70 940654053 Warning Label ............................................1
71 940778003 Hot Muffler Label .......................................1
72 308316001 Wand Holder Storage ................................1
73 660976002 * Bolt (M5 x 16 mm, Pan Hd.) ......................2
74 678390001 * Hex Nut (M5) ..............................................2
75 518986001 Vinyl Cap ....................................................2
76 940654061 Trigger Handle Warning Label
(English) .....................................................1
77 678024002 Wrench (T30 Torx) ......................................1
Not Shown:
78
N/A * Oil (SAE 30 or SAE 10W30) .......................1
79 987000254 Operator’s Manual .....................................1
80 987000255 Replacement Parts List .............................1
81 987000262 Assembly Guide .........................................1
12-19-07
(REV:00)
