60 Chapter 4
Using the TV’s Menu System
Ethernet Setup 9
Special Features 8
Auto Tuning 6
DTVLink Setup 7
Video Input Setup 5
Signal Source 4
Software Upgrade 3
Channel Search 2
Antenna Info Signal Strength 1
Go Back 0
Main Menu Connections
Press OK to measure the signal strengths of all channels to
help you adjust terrestrial TV antenna(s).
Channel 5 Antenna Input
Digital
Strength: 94
Channel 4 Antenna Input
Analog
Strength: N/A
Channel 3 Antenna Input
Analog
Strength: N/A
Channel 2 Antenna Input
Digital
Strength: 95
Channel 1 Antenna Input
Analog
Strength: N/A
Center Speaker In If you don’t have an audio amplifier connected to the
TV, choose The TV option. If you’ve connected an audio amplifier to the TV
but want to use the TV’s internal speakers as the center speaker, choose
The center channel output from an audio receiver option.
Recordings Menu
The Recordings Menu allows you to view the list of programs you’ve recorded
to the components connected to your DTVLink jacks. When you highlight and
select a program the options Cancel, Play, and Delete appear. To play a program
listed, highlight Play and press OK. You can see other DTVLink component’s
recordings by pressing the INPUT button with this menu displayed.
Connections Menu
The Connections menu specifies various ways to adjust the inputs to your
television. Items in the Connections menu are: Signal Strength, Channel Search,
Software Upgrade, Signal Source, Video Input Setup, Auto Tuning, DTVLink
Setup, Special Features, and Ethernet Setup.
Center Speaker In 4
DVI Audio Input 3
Digital Audio Out 2
Fixed/Variable Out 1
Go Back 0
Main Menu Audio
Press or to point to an option, then press OK to
select it. Press to return to the menu.
Connections
The TV's internal speakers can be used as a center speaker.
To do so, connect an external audio amplifier's center
channel output to the Internal Speaker Input on the TV.
Then select the matching option from the list above.
Warning: Connect from the audio amplifier's center
channel output and not a different output.
The center channel ouput from an audio receiver.
The TV
Select the audio source for the TV's internal speakers:
Signal Strength
This screen lists any channel EVER added to the TV. The list shows the channel
number, the station name (only when tuned, e.g. NBC), whether the channel is
digital or analog, which tuner is picking up the channel, and current signal
strength of digital channels.
When you move the highlight to the Signal Strength list, the TV attempts to tune
to that channel. You can then adjust your off-air antenna for maximum signal
strength (largest number) for the selected channel. The signal strength for a
digital channel will be shown as “- -” until the signal is strong enough for use,
then numbers will appear. Analog channels will always have the display,
“N/A”, since analog signal strength is not measured.
Only primary channels appear in the list. Digital subchannels, e.g. 8-1, 8-2, do
not appear.
Note: If you have both Antenna and Cable channels, press the
ANT•CAB button to view your Cable channels, or vice-versa.
Web Browser 8
Assisted Setup 7
Preferences 6
Connections 5
Parental Controls 4
Recordings 3
Audio Audio 2
Picture Quality 1
Go Back 0
Main Menu DTVLink (DVR10) AVDISC: 11.25 GB available
Press OK or to access the Recordings screen.
Description: Not available
No Title 1 Can 3:00PM 3/1/04
No Title 2 7:00PM 3/2/04
Trip 10:00AM 3/5/04
Summer Vacation 2:00AM 3/6/04
800 GB
Cancel
Play
Delete
Web Browser 8
Assisted Setup 7
Preferences 6
Connections 5
Parental Controls 4
Recordings 3
Audio Audio 2
Picture Quality 1
Go Back 0
Main Menu
Press OK or to access the Audio menu.
•Signal Strength: Check the signal strength of a channel.
•Channel Search: Search for available channels in your area.
•Software Upgrade: Check software version and upgrades.
•Signal Source: Lost remote? This screen changes inputs.
•Video Input Setup: Choose component or composite video.
•Auto Tuning: Create one button access to your devices.
•DTVLink Setup: Configure settings for DTVLink devices.
•Special Features: For advanced users only.
•Ethernet Setup: Configure the Ethernet connection settings.
The Connections menu has screens for specifying and
optimizing the connections (inputs) to the TV:
