8
FEATURES
Fig. 1
PRODUCT SPECIFICATIONS
Belt Size ..........................................................3 in. x 18 in.
Sanding Surface............................................... 16.5 sq. in.
No Load Speed ................................................700 ft./min. Input ......................... 120 Volts, 60 Hz, AC only, 5.3 Amps
Net Weight............................................................ 6.98 lbs.
DUST COLLECTION
BAG
REAR
HANDLE
TENSION
RELEASE
LEVER
SANDING
BELT
FRONT
HANDLE
TRACKING
KNOB
SWITCH
TRIGGER
LOCK-ON
BUTTON
BLOWER EXHAUST
HOLE
KNOW YOUR BELT SANDER
See Figure 1.
Before attempting to use this product, familiarize yourself
with all operating features and safety rules.
LOCK-ON
The lock-on feature allows you to lock the switch trigger in
the
ON position. Locking the switch trigger on allows you to
operate the sander for extended periods of time.
TENSION RELEASE LEVER
The tension release lever aids in quick and easy belt changes.
TRACKING KNOB
The tracking knob allows you to easily adjust the belt track-
ing.
DUST COLLECTION BAG
The dust collection bag attaches to the sander and keeps
dust to a minimum.
