REPAIR PARTS MODEL 425621x108A
37 F 050761L
CHASSIS & HOOD
Key
No. Part No. Description
Key
No. Part No. Description
1 1001854 Seat
2 028x23 Cap, Push 0n
3 094057 Spring
4 26x229 Screw
5 1001054 Bolt, Wing
6 017x47 Washer
7 009x56 Bolt, Shoulder
8 094154E701 Support, Seat
9 094156 Z Rod, Pivot
10 1001648E700 Bracket, Pivot
11 001x45 Bolt
12 015x89 Nut
13 009x55 Bolt, Shoulder
14 094155 Z Washer
15 164x31 Spring
16 26x249 Screw
17 26x263 Screw
18 164x30 Spring
19 1001556E285 Deck, Seat
20 15x123 Nut
21 094886E701 Plate, Lift Index
22 009x47 Screw
23 095408 Mat, Left
24 095409 Mat, Right
25 1001812E285 Hood
26 1001813E285 Grille
27 1001820 Lens
28 1001819 Housing, Light
29 1001799 Bracket, Lower Pivot
31 26x270 Screw
32 26x238 Screw
33 1001491 Bearing, Steering
34 1001594E700 Dash
35 26x201 Screw
36 093007E700 Panel, Access
37 095318E700 Support, Dash
38 1001270E701 Bracket, Rear Hanger
39 094085E700 Support, Left Grille
40 094007E701 Axle, Hanger
41 094084E700 Support, Right Grille
42 009x58 Bolt, Shoulder
43 1001928E701 Frame, Right
44 1001927E701 Frame, Left
45 690424 Container, Battery
46 1001002E701 Plate, Hitch
47 1001906E700 Plate, Rear
48 094186E700 Top, Rear Plate
49 26x277 Screw
50 015x81 Nut
51 15x124 Nut
52 690482E701 Support, Battery
53 1001816 Insert, Center Grille
54 1001817 Insert, Left Grille
55 1001818 Insert, Right Grille
56 1001814 Insert, Left Hood
57 1001815 Insert, Right Hood
59 1001755 Grommet, Parking Brake
60 1001921 Bracket, Support
61 0025x3 Screw
62 015x82 Nut
63 095218 Panel, Left Side
64 095217 Panel, Right Side
65 0193x1 Fastener, Panel
70 1001542 Holder, Cup
F 050761L Instruction Book & Parts List
