You can set your radio so the person you
are communicating with hears a tone when
you finish transmitting. To turn on the radio’s
courtesy tone, hold down

MENU/QUIET

until

9#JED;

9#JED;

9#JED;

9#JED;

flashes.

Ed

Ed

Ed

Ed

appears when the

courtesy tone is on and

E<<

E<<

E<<

E<<

appears when it

is off. Press

SCAN/

¼ý

or

¹

/CALL

to turn the

courtesy tone on or off, then press

PTT

to store

the setting. Otherwise, the radio stores the
displayed setting after about 15 seconds.

7

5+0)

"

6*'

"$

#%-.+)*6

Your radio’s display has a backlight that
turns on for about 10 seconds when you
press any key except

PTT

. To turn on the

backlight without changing the radio’s
settings, press

MON

.

±

5

'66+0)

"

6*'

"-

';

"6

10'

You can set the radio so it sounds a tone
when you press any key except

PTT

or

MON

.

To turn on the key tone, hold down

MENU/

QUIET

for about 2 seconds to enter menu

mode, then continue to press

MENU/QUIET

until

flashes..

Ed

Ed

Ed

Ed

appears when the key

tone is on and

E<<

E<<

E<<

E<<

appears when it is off.

Press

SCAN/

¼

or

¹

/CALL

to turn the key tone

on or off. Press

PTT

or

MENU/QUIET

to store

the setting or it will store the displayed
setting after 15 seconds.

7

5+0)

"

6*'

"5

9+8'.

"$

'.6

"%

.+2

To attach the belt clip, insert the clip into the
socket at the back of the radio until it clicks.
To remove the belt clip, press the button at
the top of the clip and pull out the clip.

7

5+0)

"

#0

"1

26+10#.

"

9

4+56

"5

64#2

You can attach an optional wrist strap (not
supplied) to the radio. Slide the wrist strap’s
small loop under the bar on the top of the
radio. You might need to use a small screw-
driver or straightened paper clip to do this.
Then pull the strap’s large loop through the
small loop.

%#4'

Keep the radio dry; if it gets wet, wipe it dry
immediately. Use and store the radio only in
normal temperature environments. Handle
the radio carefully; do not drop it. Keep the
radio away from dust and dirt, and wipe it
with a damp cloth occasionally to keep it
looking new.

5'48+%'"#0&"4'2#+4

If your radio is not performing as it should,
take it to your local RadioShack store for
assistance. Modifying or tampering with the
radio’s internal components can cause a
malfunction and might invalidate its warranty
and void your FCC authorization to operate it.

(%%"+0(14/#6+10

This device complies with Part 15 of the

FCC Rules

. Operation is subject to the

following two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.

When the Push-to-Talk (PTT) button is
pressed, it sends out radio frequency
signals. The device is authorized to operate
at a duty factor not to exceed fifty percent. In
August 1996, the Federal Communications
Commission adopted RF exposure
guidelines with safety levels for handheld
wireless devices.

This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the

FCC

Rules

. These limits are designed to provide

reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful interference
to radio communications.

However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an outlet on

a circuit different from that to which the
receiver is needed.

• Consult your local RadioShack store or

an experienced radio/TV technician for
help.

If you cannot eliminate the interference, the
FCC requires that you stop using your radio.

Changes or modifications not expressly
approved by RadioShack may cause
interference and void the user’s authority to
operate the equipment.

You must use shielded interface cables with
this equipment.

5#('6;"+0(14/#6+10

Do not open your radio to make any internal
adjustments. Your radio is set up to transmit
a regulated signal on one of 14 assigned
frequencies. It is illegal to alter or adjust the
settings inside the radio to exceed those
limitations. Any adjustments to your radio
must be made by a qualified technician
using the proper test equipment.

.

.

.

.

±

"016'"

±

"

You cannot turn on the backlight while the
radio is receiving a signal.

.

"%#76+10"

.

To maintain compliance with the FCC’s RF
exposure guidelines, hold the transmitter
and antenna at least 2 inches (5 cm) from
your face and speak in a normal voice, with
the antenna pointed up and away from your
face. If you wear the handset on your body
while using the headset accessory, use only
the supplied belt clip for this product and
when transmitting, take it out of the belt to
ensure the antenna is at least 1 inch (2.5
cm) from your body.

Use only the supplied antenna. Unauth-
orized antennas, modifications, or attach-
ments could damage the transmitter and
may violate FCC regulations.
