LPY2 • 12
Price: $5.00
Ramsey Publication No. MLPY2
Assembly and Instruction manual for:
RAMSEY MODEL NO. LPY2
RAMSEY ELECTRONICS, INC.
590 Fishers Station Drive
Victor, New York 14564
Phone (585) 924-4560
Fax (585) 924-4555
www.ramseykits.com
REQUIRED TOOLS
•
Soldering Iron Ramsey WLC-100,
•
Thin Rosin Core Solder Ramsey RTS12
•
Needle Nose Pliers Ramsey RTS05
•
Small Diagonal Cutters Ramsey RTS04
Complete Soldering Tool Set RS64-2801
ADDITIONAL SUGGESTED ITEMS
•
Optivisor Magnifier Headband Ramsey OPMAG
•
Holder for PC Board/Parts Ramsey RTS13,
•
Desoldering Braid Ramsey RTS08
LPY2 LOG PERIODIC ANTENNA
Quick Reference Page Guide
Introduction ........................................................4
Antenna Description ...........................................4
Standard Hook-up ..............................................5
Building a Corner Reflector ................................7
Building a Reflector Grid ....................................9
LPY2 Return Loss Plot .......................................10
Warranty ............................................................11
TOTAL SOLDER POINTS
2
ESTIMATED ASSEMBLY
TIME
Beginner ........... 1.00 hrs
Intermediate ...... .50 hrs
Advanced .......... .25 hrs
