Tv/dvd + dvd + vcr, Connections & setup – RCA HDTVMonitor/DVD User Manual
Page 13
Connections & Setup
10
Chapter 1
Graphics contained within this publication are for representation only.
Connections & Setup
Chapter 1
11
Graphics contained within this publication are for representation only.
TV/DVD + DVD + VCR
1. Connect your VCR to your TV/DVD.
A. Connect a coaxial cable to the VCR’s antenna output and to the ANTENNA/CABLE Input
jack on the TV/DVD.
B. Connect the audio (white and red) cables to the VID2 L/MONO and R Audio jacks on the
back of the TV/DVD and to the Audio Output jacks on the VCR.
C. Connect the video cable to the VID2 V (Video) jack on the back of the TV/DVD and to the
Video Output jack on the VCR.
2. Make sure cable or antenna is connected to your VCR.
Connect the coaxial cable from your cable outlet or antenna to the antenna input on the VCR.
Go to page 14
