URC1 • 21
This is a table showing the signal available at each pin of CON1, the access
number for which the pin is accessed and changed, the group number for
disabling and enabling, description, name, and range of output. “?” indicates
a variable number.
Pin # Name Device # Description Access # Range
1 VoutD 15 Level 3 *53??? 0-5V, 256 steps
2 VoutA 12 Level 0 *50??? 0-5V, 256 steps
3 VoutC 14 Level 2 *52??? 0-5V, 256 steps
4 VoutB 13 Level 1 *51??? 0-5V, 256 steps
5 +5V - V source - 5V
6 +12V - V source - 12V
7 GND - Common - 0V
8 T2 18 Timer 2 *T2??*??* 10mS to 40H
9 T0 16 Timer 0 *T0??*??* 10mS to 40H
10 T1 17 Timer 1 *T1??*??* 10mS to 40H
11 W1 9 Pot 1 Wiper *21??? 0-10K, 256 steps
12 H1 9 Pot 1 High Not adjusted 0-10K, 256 steps
13 L1 9 Pot 1 Low Not adjusted 0-10K, 256 steps
14 L0 8 Pot 0 Low Not adjusted 0-10K, 256 steps
15 H0 8 Pot 0 High Not adjusted 0-10K, 256 steps
16 W0 8 Pot 0 Wiper *20??? 0-10K, 256 steps
17 GND - Common - 0V
18 1,7 1 Output *617? 5V on off
19 0,7 0 Output *607? 5V on off
20 1,6 1 Output *616? 5V on off
21 0,6 0 Output *606? 5V on off
22 1,5 1 Output *615? 5V on off
23 0,5 0 Output *605? 5V on off
24 1,4 1 Output *614? 5V on off
25 0,4 0 Output *604? 5V on off
26 1,3 1 Output *613? 5V on off
27 0,3 0 Output *603? 5V on off
28 1,2 1 Output *612? 5V on off
29 0,2 0 Output *602? 5V on off
30 1,1 1 Output *611? 5V on off
31 0,1 0 Output *601? 5V on off
32 1,0 1 Output *610? 5V on off
33 Tone - Tone out *600? Confirm Out
34 GND - Common - 0V
Note: Pin 33 can be accessed as an output, but its value will change every time
a code is received and a tone is sent, therefore it is not recommended to be
used as an output other than for generating tones.
