www.RuggedCom.com 9 RuggedSwitch ® RSG2100
RuggedSwitch
®
RSG2100
19-Port Modular Managed Ethernet Switch with Gigabit Uplink Ports, 128-bit Encryption
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
Slot 8
Slot 9
Slot 10
Main: Ethernet and Power Connectors
„ „ „ R = Ethernet on rear; LED panel on front; power connector on rear
„ „ „ F = Ethernet on front; LED panel on front; power connector on rear
„ „ „ B = Ethernet on rear; LED panel on top; power connector on rear
„ „ „ T = Ethernet on front; LED panel on top; power connector on rear
Mount: Mounting Options
„ „ RM = 19” Rack Mount Kit
„ „ DP = DIN and Panel Mount Kit
„ „ RD = 19” Rack, DIN, and Panel Mount Kit
„ „ 00 = No Mounting Option
PS1 and PS2: Power Supply 1 and 2 (5)
„ „ 24 = 24VDC (10-36VDC), screw terminal block
„ „ 48 = 48VDC (36-72VDC), screw terminal block
„ „ HI = 88-300VDC or 85-264VAC, screw terminal block
„ „ 24P = 24VDC (10-36VDC), pluggable terminal block
„ „ 48P = 48VDC (36-72VDC), pluggable terminal block
„ „ HIP = 88-300VDC or 85-264VAC, pluggable terminal block
„ „ XX = No Power Supply (PS2 Only)
S1, S2, S3, S4, S7, S8, S9 and S10: (6)
Ethernet Modules for Slots 1, 2, 3, 4, 7, 8, 9 and 10
„ „ XXXX = Empty
„ „ TX01 = 2 x 10/100TX RJ45
„ „ TX02 = 2 x 10/100TX micro-D
„ „ FL01 = 2 x 10FL - Multimode, 850nm, ST
„ „ FX01 = 2 x 100FX - Multimode, 1300nm, ST
„ „ FX02 = 2 x 100FX - Multimode, 1300nm, SC
„ „ FX11 = 2 x 100FX - Multimode, 1300nm, LC
„ „ FX03 = 2 x 100FX - Multimode, 1300nm, MTRJ
„ „ FX04 = 2 x 100FX - Singlemode, 1310nm, ST, 20km
„ „ FX05 = 2 x 100FX - Singlemode, 1310nm, SC, 20km
„ „ FX06 = 2 x 100FX - Singlemode, 1310nm, LC, 20km
„ „ FX07 = 2 x 100FX - Singlemode, 1310nm, SC, 50km
„ „ FX08 = 2 x 100FX - Singlemode, 1310nm, LC, 50km
„ „ FX09 = 2 x 100FX - Singlemode, 1310nm, SC, 90km
„ „ FX10 = 2 x 100FX - Singlemode, 1310nm, LC, 90km
S5: Gigabit Ethernet Modules for slot 5 (6)
„ „ XXXX = Empty
„ „ CG01 = 2 x 10/100/1000Tx RJ45
„ „ CG02 = 2 x 10/100/1000TX micro-D
„ „ FG01 = 2 x 1000SX - Multimode, 850nm, LC, 500m
„ „ FG02 = 2 x 1000LX - Singlemode, 1310nm, SC connectors, 10km
„ „ FG03 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
„ „ FG04 = 2 x 1000LX - Singlemode, 1310nm, SC connectors, 25km
„ „ FG05 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
„ „ FG50 = 2 x 1000LX SFP - Blank (no optical transceiver)
„ „ FG51 = 2 x 1000SX SFP - Multimode, 850nm, LC, 500m (3)
„ „ FG52 = 2 x 1000LX SFP - Singlemode, 1310nm, LC, 10km (3)
„ „ FG53 = 2 x 1000LX SFP - Singlemode, 1310nm, LC, 25km (3)
„ „ FG54 = 2 x 1000LX SFP - Singlemode, 1550nm, LC, 70km (2)(3)
„ „ FG70 = 2 x 1000LX GBIC - Blank (no optical transceiver)
„ „ FG71 = 2 x 1000LX GBIC - Singlemode, 1310nm, SC, 10km (4)
„ „ FG72 = 2 x 1000LX GBIC - Singlemode, 1310nm, SC, 25km (4)
„ „ FG73 = 2 x 1000LX GBIC - Singlemode, 1550nm, SC, 70km (2)(4)
„ „ CG55 = 2 x 1000TX, SFP, RJ45
S6: Gigabit Ethernet Modules for slot 6 (6)
„ „ XXXXX = Empty
„ „ 1CG01 = 1 x 10/100/1000Tx RJ45
„ „ 1CG02 = 1 x 10/100/1000TX micro-D
„ „ 1FG01 = 1 x 1000SX - Multimode, 850nm, LC, 500m
„ „ 1FG02 = 1 x 1000LX - Singlemode, 1310nm, SC connectors, 10km
„ „ 1FG03 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
„ „ 1FG04 = 1 x 1000LX - Singlemode, 1310nm, SC connectors, 25km
„ „ 1FG05 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
„ „ 1FG50 = 1 x 1000SX SFP - Blank (no optical transceiver)
„ „ 1FG51 = 1 x 1000SX SFP - Multimode, 850nm,LC, 500m (3)
„ „ 1FG52 = 1 x 1000LX SFP - Singlemode, 1310nm, LC,10km (3)
„ „ 1FG53 = 1 x 1000LX SFP - Singlemode, 1310nm, LC, 25km (3)
„ „ 1FG54 = 1 x 1000LX SFP - Singlemode, 1550nm, LC, 70km (2)(3)
„ „ 1FG70 = 1 x 1000LX GBIC - Blank (no optical transceiver)
„ „ 1FG71 = 1 x 1000LX GBIC - Singlemode, 1310nm, SC, 10km (4)
„ „ 1FG72 = 1 x 1000LX GBIC - Singlemode, 1310nm, SC, 25km (4)
„ „ 1FG73 = 1 x 1000LX GBIC - Singlemode, 1550nm, SC, 70km (2)(4)
MOD: Manufacturing Modifications
„ „ XX = None
„ „ C01 = Conformal Coating
Notes:
1 Distance ratings are typical but will depend on type of cabling, number of connectors and splices.
2 These transceivers have an operating temperature range of -20 °C to +85°C.
All other transceivers have an operating temperature range of -40°C to +85°C
3 SFP plugable optics that consist of a blank cage (FG50 for dual, 1FG50 for single)
plus specified fiber optic interface(s) installed
4 GBIC plugable optics that consist of a blank cage (FG70 for dual, 1FG70 for single)
plus specified fiber optic interface(s) installed
5 PS1 and PS2 must be both either pluggable or screw terminal block
6 Switch must be ordered with at least one module installed.
Order Codes
RSG2100 - ____ - _____ - ____ - ____ - ___ - ___ - ___ - ___ - ___ - ___ - ___ - ___ - ___ - ____ - _____
Main Mount PS1 PS2 S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 MOD
