5

MODEL

IDENTIFICATION

The model number of a boiler can be found on the

Sales Order and the boiler's rating plate. The example

below identifies what the characters of the model num-

ber represent.

MODEL NUMBER EXAMPLE:

H 3 - 0 5 1 4 A

Series

Model Size
Representative of approximate MBTUH input
(Model 0514 has input of 511,500 BTUH)

Firing Mode
1

Mechanical Modulation

2

Motorized Modulation

3

2-Stage Firing

4

On-Off Firing

5

Low Temperature Mechanical Modulation

9

4-Stage Firing

Application
H = Heating Boiler

Boiler rating plate showing model number
