45
W415-0788 / A / 09.22.09
GS60 COMPONENTS
REF NO. PART NO. DESCRIPTION
31 W010-0459 ADAPTOR C/W SPILL SWITCH
32 W660-0006 SPILL SWITCH
33 W080-0405 SPILL SWITCH BRACKET
TERMINAL KITS
REF NO. PART NO. DESCRIPTION
GD-175 WALL TERMINAL KIT
34 BM6790 90° ELBOW - 7" DIAMETER
35 GD-222 TERMINAL ASSEMBLY
36 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
37 W010-1313 FIRESTOP SPACER
38* W585-0267 TOP VENT SHIELD
39* W020-0032 HARDWARE
40 BM3730 BLACK TRIM COLLAR
41 BM6724 24" STOVE PIPE - 7" DIAMETER
42* W010-0300 10' ALUMINUM FLEX LINER C/W SPACERS - 4" DIA
43* W025-0003 DECORATIVE BLACK BAND
GD-180 PERISCOPE TERMINAL KIT
34 BM6790 90° ELBOW - 7" DIAMETER
36 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
37 W010-1313 FIRESTOP SPACER
38* W585-0267 TOP VENT SHIELD
39* W020-0032 HARDWARE
40 BM3730 BLACK TRIM COLLAR
41 BM6724 24" STOVE PIPE - 7" DIAMETER
42* W010-0300 10' ALUMINUM FLEX LINER C/W SPACERS - 4" DIA
43 W025-0003 DECORATIVE BLACK BAND
44 GD-201 PERISCOPE
**FOR OTHER AVAILABLE COLOURS, ADD THESE LETTERS TO THE BASE PART NUMBER:
COLOR LETTER FINISH
MAJOLICA BROWN
N PORCELAIN
COMMON COMPONENTS
REF NO. PART NO. DESCRIPTION
26 W135-0377** SIDE (LEFT OR RIGHT)
27 W135-0375** TOP
28 W135-0376** FRONT
29* W010-0648 GLASS WITH GASKET
30* W190-0029 CONTROL MODULE - EI
