Napoleon Fireplaces GDS60N User Manual
Page 2
2
W415-0788 / A / 09.22.09
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION
OVERVIEW
3
2.0 INTRODUCTION
4
2.1 DIMENSIONS
5
2.2 GENERAL
INSTRUCTIONS
5
2.3 GENERAL
INFORMATION
6
2.4 RATING
PLATE
7
2.5
CARE OF GLASS
8
2.6 SHIPPING
BRACKET
8
3.0
VENTING - MODEL GDS60
9
3.1
VENTING LENGTHS AND COMPONENTS
10
3.2
TYPICAL VENT INSTALLATIONS
11
3.3
SPECIAL VENT INSTALLATIONS
13
3.3.1 PERISCOPE
TERMINATION
13
3.3.2 CORNER
TERMINATION
13
3.4 VENT
TERMINAL
CLEARANCES
14
3.5
VENTING APPLICATION FLOW CHART
15
3.6 DEFINITIONS
16
3.7
ELBOW VENT LENGTH VALUES
16
3.8
TOP EXIT HORIZONTAL TERMINATION
17
3.9
TOP EXIT HORIZONTAL TERMINATION
18
3.10
REAR EXIT HORIZONTAL TERMINATION
19
3.11
TOP OR REAR EXIT VERTICAL TERMINATION
21
4.0
INSTALLATION PREPARATION - MODEL GDS60
23
4.1 ORIFICE
REPLACEMENT
23
4.2
CHANGING A TOP VENT TO A REAR VENT
24
5.0 INSTALLATION
25
5.1
MINIMUM CLEARANCE TO COMBUSTIBLES
25
5.2
WALL AND CEILING PROTECTION
26
5.2.1 HORIZONTAL
INSTALLATION
26
5.2.2 VERTICAL
INSTALLATION
27
5.2.3
HORIZONTAL AIR TERMINAL INSTALLATION - MODEL GDS60
27
5.2.4
VERTICAL AIR TERMINAL INSTALLATION - MODEL GDS60
28
5.3
APPLIANCE VENT CONNECTION - MODEL GDS60
29
5.4
MOBILE HOME INSTALLATION - MODEL GDS60
29
5.5 GAS
INSTALLATION
29
5.6
OPTIONAL WALL SWITCH / THERMOSTAT
30
5.7
B-VENT SPECIFICS - MODEL GS60
30
5.7.1 CHIMNEY
INSTALLATION
30
5.7.2
INSTALLING "B" VENT
31
5.7.3 B-VENT
31
5.7.4 COMBUSTION
AIR
31
5.7.5
ADDING VENT SECTIONS
32
5.7.6
INSTALLING FLASHING AND STORM COLLAR
33
6.0 FINISHING
34
6.1
FRONT CAST REMOVAL
34
6.2
GLASS DOOR INSTALLATION AND REMOVAL
34
6.3
GLASS / DOOR REPLACEMENT
35
6.4 LOG
PLACEMENT
35
6.5 LOGO
PLACEMENT
36
6.6
SWITCH AND BRACKET INSTALLATION
37
7.0
OPTIONAL BLOWER INSTALLATION
38
8.0 WIRING
DIAGRAM
39
9.0 OPERATION
40
9.1 OPERATING
INSTRUCTIONS
40
9.2
OPERATING INSTRUCTIONS - FOR YOUR SAFETY READ BEFORE OPERATING
41
9.3 LIGHTING
INSTRUCTIONS
41
9.4
ANTI CONDENSATION SWITCH
41
10.0 ADJUSTMENT
42
10.1 PILOT
BURNER
ADJUSTMENT
42
10.2 VENTURI
ADJUSTMENT
42
10.3 FLAME
CHARACTERISTICS
42
10.4
RESTRICTING VERTICAL VENTS - MODEL GDS60
42
11.0 MAINTENANCE
43
12.0 REPLACEMENTS
44
13.0 TROUBLE
SHOOTING
48
14.0 WARRANTY
51
15.0 SERVICE
HISTORY
52
