COMMON REPLACEMENT PARTS:
37* W175-0166 5" COUPLER
37* W175-0002 8" COUPLER
38 L36K LOUVRE KIT - UPPER & LOWER - BLACK
38 L36PB LOUVRE ASSEMBLY - POLISHED BRASS
38 L36AB LOUVRE ASSEMBLY - ANTIQUE BRASS
38 L36SS LOUVRE ASSEMBLY - BRUSHED STAINLESS STEEL
39* W573-0007 10.3OZ TUBE HIGH TEMP SEALANT
40* W690-0001 MILLIVOLT THERMOSTAT
41* W660-0011 REMOTE CONTROL - ADVANTAGE PLUS
42* W500-0028 FIRESTOP SPACER - FLEXIBLE VENTING
42* W500-0163 FIRE STOP SPACER - RIGID VENTING
43* W500-0206 TERMINAL EXTENSION PLATE
44* W660-0013 MODULATING REMOTE
45 W170-0086 VENT PIPE COLLAR
46 W585-0092 VENT PIPE SHIELD
47 GZ550-1KT BLOWER KIT
48* GD36 THERMOSTATIC SENSOR CONTROL KIT FOR USE WITH GD 65 ONLY
49 HOIK-2 HERITAGE ORNAMENTAL INSETS - BLACK
49 HOIG-2 HERITAGE ORNAMENTAL INSETS - GOLD PLATED
49 HOIKG-2 HERITAGE ORNAMENTAL INSETS - BLACK GOLD PLATED
49 HOIBC-2 HERITAGE ORNAMENTAL INSETS - BRUSHED COPPER PLATED
49 HOIBG-2 HERITAGE ORNAMENTAL INSETS - BRUSHED GOLD PLATED
50 DOIK-1 DIAMOND ORNAMENTAL INSETS - BLACK
50 DOIG-1 DIAMOND ORNAMENTAL INSETS - GOLD PLATED
50 DOIKG-1 DIAMOND ORNAMENTAL INSETS- BLACK GOLD PLATED
50 DOIBC-1 DIAMOND ORNAMENTAL INSETS- BRUSHED COPPER PLATED
50 DOIBG-1 DIAMOND ORNAMENTAL INSETS- BRUSHED GOLD PLATED
51 GOIK-1 GOTHIC ORNAMENTAL INSETS - BLACK
51 GOIG-1 GOTHIC ORNAMENTAL INSETS - GOLD PLATED
51 GOIKG-1 GOTHIC ORNAMENTAL INSETS - BLACK GOLD PLATED
51 GOIBC-1 GOTHIC ORNAMENTAL INSETS - BRUSHED COPPER PLATED
51 GOIBG-1 GOTHIC ORNAMENTAL INSETS - BRUSHED GOLD PLATED
52 SOIK-1 SEASHELL ORNAMENTAL INSETS - BLACK
52 SOIG-1 SEASHELL ORNAMENTAL INSETS - GOLD PLATED
52 SOIKG-1 SEASHELL ORNAMENTAL INSETS - BLACK GOLD PLATED
52 SOIBC-1 SEASHELL ORNAMENTAL INSETS - BRUSHED COPPER PLATED
52 SOIBG-1 SEASHELL ORNAMENTAL INSETS - BRUSHED GOLD PLATED
53 EOIK-1 ECLIPSE ORNAMENTAL INSETS - BLACK
53 EOIG-1 ECLIPSE ORNAMENTAL INSETS - GOLD PLATED
53 EOIKG-1 ECLIPSE ORNAMENTAL INSETS - BLACK GOLD PLATED
53 EOIBC-1 ECLIPSE ORNAMENTAL INSETS - BRUSHED COPPER PLATED
53 EOIBG-1 ECLIPSE ORNAMENTAL INSETS - BRUSHED GOLD PLATED
54 DK36-R DOOR KIT, RECTANGULAR - BLACK
54 DK36-RG DOOR KIT, RECTANGULAR - GOLD PLATED
55 DK36-A DOOR KIT, ARCHED - BLACK
55 DK36-AG DOOR KIT, ARCHED - GOLD PLATED
56 DK36-W DOOR KIT, WEBBED - BLACK
56 DK36-WG DOOR KIT, WEBBED - GOLD PLATED
57 GA-566 HOT AIR KIT
58 GA-72 HOT AIR EXHAUST KIT
59 GA-70 EXTENSION KIT 5 FT
60* W175-0235 CONVERSION KIT - NG TO LP
60* W175-0236 CONVERSION KIT - LP TO NG
61* GD808-KT DECORATIVE PANELS - SANDSTONE
62* PRP36-D PORCELAIN PANELS
# PART NO. DESCRIPTION
1* W225-0058 BLACK DOOR FRAME
2 W357-0001 PIEZO IGNITER
3* W680-0004 THERMOPILE
4* W680-0005 THERMOCOUPLE
5* W010-0800 PROPANE GAS PILOT ASSEMBLY
5* W010-0801 NATURAL GAS PILOT ASSEMBLY
6* W455-0069 NATURAL GAS PILOT INJECTOR
6* W455-0067 PROPANE GAS PILOT INJECTOR
7 W455-0065 #45 NATURAL GAS ORIFICE
7 W455-0003 #54 PROPANE GAS ORIFICE
8 W725-0035 NATURAL GAS VALVE
8 W725-0043 PROPANE GAS VALVE
9* W385-0334 NAPOLEON LOGO
10* W750-0112 20FT OF WIRE
11 W010-0764 PAN BURNER
12* GL-639 LOG SET
13* W361-0016 GLOWING EMBERS
14* W550-0001 CHARCOAL EMBERS
15 W135-0183 BACK LOG (#1)
16 W135-0184 LEFT MIDDLE LOG (#2)
17 W135-0185 RIGHT MIDDLE LOG (#3)
18 W135-0186 LEFT CROSSOVER LOG (#4)
19 W135-0187 MIDDLE CROSSOVER LOG (#5)
20 W135-0188 RIGHT CROSSOVER LOG (#6)
21 W010-0454 GLASS c/w GASKET
22 W010-0516 BLACK DOOR C/W GLASS
23 W500-0028 FIRESTOP SPACER
24* W500-0205 RESTRICTOR
GD420 (5 FT)
25* W010-0772 5" FLEXIBLE ALUMINIUM LINER - (5 FT ) C / W SPACERS
25* W730-0012 8" FLEXIBLE ALUMINIUM LINER - (5 FT )
GD430 (10 FT)
25* W730-0013 8" FLEXIBLE ALUMINIUM LINER -(10 FT )
25* W010-0773 5" FLEXIBLE ALUMINIUM LINER -(10 FT ) C / W SPACERS
26* W010-0810 WALL SUPPORT ASSEMBLY
27 PERISCOPE - GD401
28 WALL TERMINAL KIT - GD422
29 1/12 TO 7/12 PITCH - GD410
30 8/12 TO 12/12 PITCH - GD411
31 FLAT ROOF - GD412
32 W490-0074 5/8 INNER/OUTER SLEEVE
33 W670-0007 5/8 TERMINAL
34 W170-0086 STORM COLLAR
35 W010-0453 ROOF SUPPORT
36 W263-0065 / ROOF FLASHING
W263-0066 /
W263-0055
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the follow-
ing information:
1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
REPLACEMENTS
ACCESSORIES:
FLEXIBLE VENT KITS
TERMINAL KITS
ROOF TERMINAL KITS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR FUR
-
THER INFORMATION , CONTACT YOUR NAPOLEON DEALER .
