6. Make sure that all parts are properly tightened before you use the treadmill. Keep the included allen

wrenches for adjustment purposes. To protect the floor or carpet from damage, place a mat under the tread-
mill.

5. After the treadmill is placed in the location where it will

be used (see HOW TO MOVE THE TREADMILL on
page 9), make sure that both Rear Feet (5) and both
front Wheels (not shown) rest firmly on the floor. If the
treadmill rocks even slightly, turn the right Rear Foot
clockwise or counterclockwise until the rocking motion
is eliminated.

4. Refer to step 1. While a second person holds the

Uprights (95, 97), remove the two Upright Bolts (96).

Slide the Uprights (95, 97) fully onto the brackets on the
Frame (not shown). Be careful to avoid pinching your
hands or the wires. Attach each Upright with four
Upright Bolts (96) as shown. Firmly tighten all eight
Upright Bolts.

Firmly tighten the eight Handrail Bolts (99).
