E Copyright Nokia Networks Oy C33902002SE_00 3
Figure 3 MW1122 front panel indicators
DSL GREEN
Off ADSL link is down.
Blinks ADSL connection is being established.
On ADSL link is up.
ETH GREEN
Off Ethernet is down.
On 10Base-T Ethernet is functional
Blinks Receives traffic from Ethernet.
COL GREEN
Blinks Collisions on the Ethernet. Note, that it is normal that some
collisions occur on the Ethernet.
WLAN GREEN
Off No stations on the WLAN or WLAN PC Card not
inserted.
On Stations on the WLAN but no traffic.
Blinks Receives traffic through the WLAN interface.
