E Copyright Nokia Networks Oy C33902002SE_00 32
payload encapsulation formats. WFQ works properly only with
IP-based protocols. If the flow is IP-based but is encrypted using IPSec
or PPP encryption, then WFQ cannot identify the flows correctly. In
this case, the default flow is used and the default flow is treated as a
single flow.
5 Technical specifications
Features
ADSL
Physical layer ANSI T1.413 Issue 2 (ANSI ADSL), ITU-T
G.992.1 (ITU-T ADSL), and ITU-T G.994.1
(Handshake) compatible.
ADSL line connector RJ-11
ATM over ADSL
ATM connections PVC, up to 8 virtual circuits
Service categories UBR
Encapsulations RFC2684 ETH-LLC, RFC2684 IP-LLC,
RFC2364 PPP-VC, RFC2364 TUNNELED-
PPP-VC
Ethernet interface
Ethernet 10Base-T, half duplex
Encapsulation DIXv2 (transmit), IEEE 802.3 and DIXv2 (re-
ceive)
Ethernet connectors RJ-45
Wireless LAN interface
Wireless LAN IEEE 802.11b DSSS
Data connector PC Card slot type 2
Routing
Routing protocols RIPv1, RIPv2, and static routes
Other NAPT, IGMP proxy, DHCP server, DNS relay,
PPTP local tunneling
Class of Service Weighted fair queueing
