21
W415-0098 / C / 04.19.06
GD175 WALL TERMINAL KIT
47 BM6790 90° ELBOW - 7" DIAMETER
48 GD222 TERMINAL ASSEMBLY
49 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
50 W500-0077 FIRESTOP / WALL PLATE
51 W020-0032 HARDWARE
52 BRTC7 BRASS TRIM COLLAR
53 BM6724 24" STOVE PIPE - 7" DIAMETER
54 W010-0300 10' ALUMINUM FLEX LINER C / W SPACERS - 4" DIA
55 W025-0001 DECORATIVE BRASS BAND
GD180 PERISCOPE
47 BM6790 90° ELBOW - 7" DIAMETER
56 GD201 PERISCOPE
49 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
50 W500-0077 FIRESTOP / WALL PLATE
51 W020-0032 HARDWARE
52 BRTC7 BRASS TRIM COLLAR
53 BM6724 24" STOVE PIPE - 7" DIAMETER
54 W010-0300 10' ALUMINUM FLEX LINER C / W SPACERS - 4" DIA
55 W025-0001 DECORATIVE BRASS BAND
GD110 - 1/12 TO 7/12 PITCH
57 W670-0006 AIR TERMINAL
58 W490-0073 4/7 INNER/OUTER SLEEVE
59 W010-0567 ROOF SUPPORT
60 W263-0054 ROOF FLASHING
61 W170-0063 STORM COLLAR
GD111 - 8/12 TO 12/12 PITCH
57 W670-0006 AIR TERMINAL
58 W490-0073 4/7 INNER/OUTER SLEEVE
59 W010-0567 ROOF SUPPORT
60 W263-0055 ROOF FLASHING
61 W170-0063 STORM COLLAR
GD112 - FLAT ROOF
57 W670-0006 AIR TERMINAL
58 W490-0073 4/7 INNER/OUTER SLEEVE
59 W010-0567 ROOF SUPPORT
60 W263-0056 ROOF FLASHING
61 W170-0063 STORM COLLAR
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the follow-
ing information: 1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR FOR FOR FOR FOR WARRANTY WARRANTY WARRANTY WARRANTY WARRANTY REPL REPL REPL REPL REPLA A A A ACEMENT CEMENT CEMENT CEMENT CEMENT P P P P PAR AR AR AR ARTS TS TS TS TS
, , , , ,
A A A A A PHO PHO PHO PHO PHOT T T T TOCOPY OCOPY OCOPY OCOPY OCOPY OF OF OF OF OF THE THE THE THE THE
ORIGINAL ORIGINAL ORIGINAL ORIGINAL ORIGINAL INVOICE INVOICE INVOICE INVOICE INVOICE WILL WILL WILL WILL WILL BE BE BE BE BE REQUIRED REQUIRED REQUIRED REQUIRED REQUIRED TO TO TO TO TO HONOUR HONOUR HONOUR HONOUR HONOUR THE THE THE THE THE CLAIM CLAIM CLAIM CLAIM CLAIM
.....
REPLACEMENTS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR
FURTHER INFORMATION
,
CONTACT YOUR NAPOLEON
DEALER
.
TERMINAL KITS
ROOF TERMINAL KITS
COMPONENTS COMMON TO BOTH UNITS:
# PART # DESCRIPTION
1 W725-0042 SIT VALVE - NG
1 W725-0043 SIT VALVE - LP
2 W100-0046 TURBO REAR BURNER
3 W100-0040 FRONT BURNER
4 W455-0037 #43 REAR BURNER ORIFICE - NG
4 W455-0034 #57 REAR BURNER ORIFICE - LP
4 W455-0043 #45 REAR BURNER ORIFICE - H I A LT NG
4 W455-0035 #59 REAR BURNER ORIFICE - H I A LT LP
5 W455-0045 #34 FRONT BURNER ORIFICE - NG
5 W455-0033 #53 FRONT BURNER ORIFICE - LP / H I A LT LP
5 W455-0044 #36 FRONT BURNER ORIFICE - H I A LT NG
6 W010-0800 PILOT ASSEMBLY - LP
6 W010-0801 PILOT ASSEMBLY - NG
7 W455-0068 PILOT INJECTOR - LP
7 W455-0070 PILOT INJECTOR - NG
8 W680-0005 THERMOCOUPLE
9 W680-0004 THERMOPILE
10 W290-0029 PILOT GASKET
11 W380-0001 TURBO CONTROL KNOB
12 W010-0087 TURBO VALVE - NG
12 W010-0175 TURBO VALVE - LP
13 GS-530K BLACK TRIVET
14 W357-0001 PIEZO IGNITOR
15 W715-0195 PEDESTAL TRIM
16 GL-642 LOG SET
17 W135-0194 BASE LOG (#1)
18 W135-0195 MIDDLE CROSSOVER LOG (#2)
19 W135-0196 RIGHT CROSSOVER LOG (#3)
20 W135-0197 LEFT CHUNK (#4)
21 W135-0027 CHARCOAL EMBER STRIP
22 W290-0030 BURNER GASKET
23 W562-0022 GLASS GASKET
24 W385-0245 NAPOLEON LOGO
25 W300-0029 FRONT WINDOW GLASS
26 W030-0021 ACCENT BAR
27 W300-0028 SIDE WINDOW GLASS
28 GDS63 BLOWER c/w GASKET
29 W225-0086G DOOR (FRAME ONLY)
30 W010- 0715G GOLD DOOR COMPLETE
31 W290-0032 RELIEF HOUSING GASKET
32 W430-0002 MAGNETIC CLOSURE
33 W290-0031 AIR MANIFOLD GASKET
34 W390-0001 LATCH
35 W750-0009 ELECTRODE WIRE
36 W660-0009 ON/OFF SWITCH
37 W690-0002 THERMODISC
38 W434-0001 MIRROR
39 W500-0111 COMBUSTION AIR COVER PLATE
40 W290-0033 COMBUSTION AIR GASKET
41 W380-0002 VARIABLE SPEED SWITCH KNOB
42 KB-35 VARIABLE SPEED SWITCH
43 W010-0459 ADAPTER C / W SPILL SWITCH
44 W660-0006 SPILL SWITCH
45 W060-0003 TERMINAL BLOCK
46 W025-0001 DECORATIVE BRASS BAND
41 W380-0002 VARIABLE SPEED SWITCH KNOB
42 KB-35 VARIABLE SPEED SWITCH
GDS50 COMPONENTS
GS50 COMPONENTS
# PART # DESCRIPTION
62 GS-530G GOLD PLATED TRIVET
63 W690-0001 MILLIVOLT THERMOSTAT
64 W660-0011 REMOTE CONTROL - ADVANTAGE PLUS
65 BM6745 45° ELBOW
66 GD301 HEAT GUARD
67 W175-0001 4" COUPLER
68 W573-0007 10.3OZ TUBE HIGH TEMP SEALANT
69 GS-150KT ADAPTER KIT
ACCESSORIES:
GDS50 ACCESSORIES
GS50 ACCESSORIES
